JUMO LOGOSCREEN nt Interface Description

49
7 Address tables
0x012A R word Available as of firmware 187.04.xx:
External analog alarms 1 channel 33...48
0x012B R word Available as of firmware 187.04.xx:
External analog alarms 1 channel 49...54
0x012C R word Available as of firmware 187.04.xx:
External analog alarms 2 channel 33...48
0x012D R word Available as of firmware 187.04.xx:
External analog alarms 2 channel 49...54
0x012E R word Available as of firmware 187.04.xx:
External binary inputs alarm 33...48
0x012F R word Available as of firmware 187.04.xx:
External binary inputs alarm 49...54
0x1000 R char 46 Device name
0x1017 R/W byte Brightness of the display
0x120F R long Highspeed counter B1 (HW counter B1)
The normal counters 1 … 27 cannot be
read out via Modbus but only via the
highspeed counters.
0x1211 R long Highspeed counter B2 (HW counter B2)
0x1213 R long Highspeed counter B9 (HW counter B9)
0x1215 R long Highspeed counter B10 (HW counter B10)
0x1217 R long Highspeed counter B17 (HW counter B17)
0x1219 R long Highspeed counter B18 (HW counter B18)
0x121B R char 11 Software version card 1
0x1221 R char 11 Software version card 2
0x1227 R char 11 Software version card 3
0x122D R char 11 Software version Profibus
Address Access Data type Signal designation
0x1257 R float Analog process value 1 (filtered)
0x1259 R float Analog process value 2 (filtered)
0x125B R float Analog process value 3 (filtered)
0x125D R float Analog process value 4 (filtered)
0x125F R float Analog process value 5 (filtered)
0x1261 R float Analog process value 6 (filtered)
0x1263 R float Analog process value 7 (filtered)
0x1265 R float Analog process value 8 (filtered)
0x1267 R float Analog process value 9 (filtered)
0x1269 R float Analog process value 10 (filtered)
0x126B R float Analog process value 11 (filtered)
0x126D R float Analog process value 12 (filtered)
0x126F R float Analog process value 13 (filtered)
0x1271 R float Analog process value 14 (filtered)
0x1273 R float Analog process value 15 (filtered)
0x1275 R float Analog process value 16 (filtered)
0x1277 R float Analog process value 17 (filtered)
0x1279 R float Analog process value 18 (filtered)
