0108.USA
D 8
3.3 Mast version
3.4 US Standards
Continuous sound pressure level at ear:
58 db(A)
as per ASME B56.11.5 test procedures ASME
NOTICE The continuous sound level is a value averaged according to standard
regulations, taking the sound pressure level into account when driving, lifting
and idling. The sound pressure level is measured at the ear.
Vibration: a
w,zS
= 3.65 ft/s
2
(1.11 m/s
2
).
NOTICE The swinging acceleration acting on the body in its operating position is the
linear integrated, weighted acceleration in the vertical plane. It is determined
by driving over bumps with a constant speed.
Description EKS 314 (TL/ZT)
h
1
Retracted height 91.3 - 189 inch 2320 - 4800 mm
h
3
Lift 118.1 - 315 inch 3000 - 8000 mm
h
4
Extended height 209.5 - 406.3 inch 5320 - 10320 mm
h
6
Height above overhead guard 91.3 inch 2320 mm
h
12
Truck height raised 126.4 - 323.2 inch 3210 - 8210 mm
h
15
Stockpicking height 189.4 - 386.2 inch 4810 - 9810 mm
Description EKS 314 (TL/DZ)
h
1
Retracted height 91.3 - 137 inch 2320 - 3480 mm
h
3
Lift 137.8 - 315.4 inch 3500 - 8010 mm
h
4
Extended height 229.1 - 406.7 inch 5820 - 10330 mm
h
6
Height above overhead guard 91.3 inch 2320 mm
h
12
Truck height raised 146.1 - 323.6 inch 3710 - 8220 mm
h
15
Stockpicking height 209.1 - 386.6 inch 5310 - 9820 mm
0108.USA
D 8
3.3 Mast version
3.4 US Standards
Continuous sound pressure level at ear:
58 db(A)
as per ASME B56.11.5 test procedures ASME
NOTICE The continuous sound level is a value averaged according to standard
regulations, taking the sound pressure level into account when driving, lifting
and idling. The sound pressure level is measured at the ear.
Vibration: a
w,zS
= 3.65 ft/s
2
(1.11 m/s
2
).
NOTICE The swinging acceleration acting on the body in its operating position is the
linear integrated, weighted acceleration in the vertical plane. It is determined
by driving over bumps with a constant speed.
Description EKS 314 (TL/ZT)
h
1
Retracted height 91.3 - 189 inch 2320 - 4800 mm
h
3
Lift 118.1 - 315 inch 3000 - 8000 mm
h
4
Extended height 209.5 - 406.3 inch 5320 - 10320 mm
h
6
Height above overhead guard 91.3 inch 2320 mm
h
12
Truck height raised 126.4 - 323.2 inch 3210 - 8210 mm
h
15
Stockpicking height 189.4 - 386.2 inch 4810 - 9810 mm
Description EKS 314 (TL/DZ)
h
1
Retracted height 91.3 - 137 inch 2320 - 3480 mm
h
3
Lift 137.8 - 315.4 inch 3500 - 8010 mm
h
4
Extended height 229.1 - 406.7 inch 5820 - 10330 mm
h
6
Height above overhead guard 91.3 inch 2320 mm
h
12
Truck height raised 146.1 - 323.6 inch 3710 - 8220 mm
h
15
Stockpicking height 209.1 - 386.6 inch 5310 - 9820 mm
