D 1
0108.USA
D Truck Description
1 Application
The EKS 314 is an electric stockpicker. It is designed to be used on level surfaces to
transport and pick goods. The floor surface must comply with the following require-
ments:
Floor specifications
QwW In order to prevent accidents due to operation on uneven floor surfaces the
following floor surface tolerances must not be exceeded.
Max. permitted height differences (h) across the aisle:
Floor planeness / tolerances lengthwise to the tracks for both height classes
– Floor has to be oil and grease resistant.
– Floor leakage resistance RE is not permitted to pass 10
6
Ω.
– Floor surface must be carefully finished to eliminate all short floor waves.
Axle width (S)
up to 1 m
up to 40 inch
more than 1,0 m
up to 1,5 m
more than 40 inch
up to 59 inch
more than 1,5 m
up to 2,0 m
more than 59 inch
up to 79 inch
more than 2,0 m
up to 2,5 m
more than 59 inch
up to 98 inch
Max. permitted
height difference
between outer tracks (SP)
VNA truck lift height
</= 6 m / </= 236 inch
VNA truck lift height
> 6,01 m / > 236 inch
2,0 mm
0.08 inch
2,5 mm
0.10 inch
3,0 mm
0.12 inch
3,5 mm
0.14 inch
1,5 mm
0.06 inch
2,0 mm
0.08 inch
2,5 mm
0.10 inch
3,0 mm
0.12 inch
Distance of
measuring points
1,0 m /
39.34 inch
2,0 m /
78.68 inch
3,0 m /
118.02 inch
4,0 m /
157.36 inch
Max. permitted tolerance/
planeness
Bulk sample as limit value
2,0 mm
0.08 inch
3,0 mm
0.12 inch
4,0 mm
0.16 inch
5,0 mm
0.20 inch
D 1
0108.USA
D Truck Description
1 Application
The EKS 314 is an electric stockpicker. It is designed to be used on level surfaces to
transport and pick goods. The floor surface must comply with the following require-
ments:
Floor specifications
QwW In order to prevent accidents due to operation on uneven floor surfaces the
following floor surface tolerances must not be exceeded.
Max. permitted height differences (h) across the aisle:
Floor planeness / tolerances lengthwise to the tracks for both height classes
– Floor has to be oil and grease resistant.
– Floor leakage resistance RE is not permitted to pass 10
6
Ω.
– Floor surface must be carefully finished to eliminate all short floor waves.
Axle width (S)
up to 1 m
up to 40 inch
more than 1,0 m
up to 1,5 m
more than 40 inch
up to 59 inch
more than 1,5 m
up to 2,0 m
more than 59 inch
up to 79 inch
more than 2,0 m
up to 2,5 m
more than 59 inch
up to 98 inch
Max. permitted
height difference
between outer tracks (SP)
VNA truck lift height
</= 6 m / </= 236 inch
VNA truck lift height
> 6,01 m / > 236 inch
2,0 mm
0.08 inch
2,5 mm
0.10 inch
3,0 mm
0.12 inch
3,5 mm
0.14 inch
1,5 mm
0.06 inch
2,0 mm
0.08 inch
2,5 mm
0.10 inch
3,0 mm
0.12 inch
Distance of
measuring points
1,0 m /
39.34 inch
2,0 m /
78.68 inch
3,0 m /
118.02 inch
4,0 m /
157.36 inch
Max. permitted tolerance/
planeness
Bulk sample as limit value
2,0 mm
0.08 inch
3,0 mm
0.12 inch
4,0 mm
0.16 inch
5,0 mm
0.20 inch
