– Undo the battery retainer (8) by moving the lever (9) down and remove the retainer.

– Pull the battery (6) onto the side of the prepared battery trolley.

QwW Make sure the battery trolley is properly secured.

QwW After replacing/fitting the battery (6), make sure that the battery is well

secured in the battery compartment.

NOTICE The battery retainers (7, 8) can swap positions. This means that they can

both be fitted in either the left or right side of the truck’s chassis.

Assembly is the reverse order.

QwW To avoid pushing the battery (6) through on assembly, the battery retainer (7)

must first be plugged in on the opposite side.

QwW After installing again, check all cables and connectors for signs of visible

damage and before using the truck again check that:

– the battery retainer (8) is fitted and secured by the lever (9),

– the right and left side sections (3) are securely fitted and the battery panel (4) is

firmly closed.
