Jungheinrich ERC 214 User Manual

Ite
m
Control/display ERC
212/214/216
212z/214z/
216z
Function
60 Keypad
o
Replaces the key switch
– Provided only as a supplement to the
display unit
– Truck release by entering set-up and
access codes
Transponder
reader
o
Replaces the key switch
– Provided only as a supplement to the
display unit
– Activates the truck via a card/transponder
61 Terminal board
t
– Paper storage.
17 On-board battery
charger mains
connector
o
Used to charge the battery with an on-board
battery charger (o), see page 50.
8 Travel switch
t
– Controls the travel direction and the
speed.
9 Collision safety
switch
t
Pedestrian mode:
Safety function when travelling in drive
direction:
– When applied, the truck travels for
approx. 3 seconds in the load direction.
The parking brake then applies. The truck
remains switched off until the travel switch
is set to neutral.
Rider mode:
– No function.
o
Pedestrian mode and rider mode:
Safety function when travelling in drive
direction:
– When applied, the truck travels for
approx. 3 seconds in the load direction.
The parking brake then applies. The truck
remains switched off until the travel switch
is set to neutral.
18 Emergency
disconnect switch
t
Disconnects the battery supply
– All electric functions are cut out and the
truck is braked.
62 Warning signal
(horn) button
t
– Warning signal button
5 Tiller
t
– Set to brake zone (B) (see page 83):
The truck brakes regeneratively.
– Set to travel zone (F) (see page 83):
The mechanical brake is released when
the travel switch truck is moved, and the
truck is ready for operation.
67
04.19 en-GB
