Travelling in pedestrian mode
Requirements
– Start up the truck, see page 72
Procedure
• Swing both folding side arms (13) in.
Z
Both side arms must be folded in at all times otherwise all functions will be
deactivated (E-1926).
Z
With a load backrest (o) all functions are not deactivated if both side arms are
folded out in pedestrian mode.
• Fold up the operator platform (15).
• Swing the tiller (5)in to the travel zone (F).
• Push the travel switch (8) to the desired travel direction: forward (V) or reverse
(R).
Z
When the travel switch is released, it automatically returns to the neutral position.
• Control the travel speed with the travel switch (8).
The brakes are released and the truck moves in the selected direction.
Z
In pedestrian mode the truck can only operate at reduced speed.
85
04.19 en-GB
