39
08.11 EN
C Transport and Commissioning
1 Transport
Transport can be carried out in two different ways, depending on the height of the
mast and the local conditions.
– Vertically, with the mast assembled (for low heights)
– Vertically, with the mast dismantled (for large heights), all mechanical connections
and hydraulic lines between the basic truck and the mast separated.
2 Truck laden
2.1 Centre of gravity of the truck
WARNING!
Altering the centre of gravity can be hazardous
The overall centre of gravity can vary depending on the truck's equipment (especially
the mast version).
XFor masts with a low height the centre of gravity will move towards the
counterweight.
XFor masts with a greater height the centre of gravity will move towards the centre
of the truck.
The picture shows the approximate centre of
gravity location.
