3. Connect the other end of the grounding cable to a proper earth ground, such as the rack.
4. Dress the grounding cable and ensure that it doesn’t touch or block access to other device components, and that it
doesn’t drape where people could trip over it.
5. Ensure that the power supplies are fully inserted in the chassis and the latches are secure.
6. For each power supply, ensure that the loop on the power cord retainer is open and there’s enough space to insert
the power cord coupler into the inlet. If the loop is closed, press the small tab on the retainer to loosen the loop.
7. On the rst power supply, thread the power cord coupler through the power cord retainer loop.
8. Plug in the power cord to the power supply socket.
9. Slide the power cord retainer loop toward the power supply unl the loop is snug against the base of the coupler.
10. Press the tab on the loop, and draw out the loop into a ght circle.
5
