4. Enter the root password you want to use for this device. You are prompted to re-enter the root password.
5. Enter yes to enable services like Telnet and SSH.
NOTE: You cannot log in to the switch as the user root through Telnet—you must first configure other users.
Root login is only allowed through SSH.
6. Use the Management Options page to select the management scenario:
•
In-band Management—Use VLAN ‘default’ for management
•
In-band Management—Create new VLAN for management
Select this option to create a management VLAN. Specify the VLAN name, VLAN ID, management IP address, and
default gateway for the new VLAN. Select the ports that must be part of this VLAN.
•
Out-of-band Management—Configure management port
Select this option to configure only the management interface. Specify the IP address and default gateway for the
management interface.
7. (Optional) Specify the SNMP Read Community, Location, and Contact to configure SNMP parameters.
8. (Optional) Specify the system date and time. Select the time zone from the list.
9. The configured parameters are displayed. Enter yes to commit the configuration. The configuration is committed as
the active configuration for the switch.
You can now log in with the CLI to continue configuring the switch.
Step 3: Keep Going
IN THIS SECTION
Safety Warnings Summary | 7
Power Cable Warning (Japanese) | 7
Contacting Juniper Networks | 8
6

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
