Step 2: Up and Running
IN THIS SECTION
Plug and Play | 10
Customize the Basic Conguraon Using the CLI | 10
Now that the EX4100 and EX4100-F switch is powered on, let’s do some inial conguraon to get the switch up and
running on your network. It’s simple to provision and manage the switch and other devices on your network. Choose
the conguraon tool that’s right for you:
• Juniper Mist. To use Mist, you’ll need an account on the Mist Cloud Plaorm. See Overview of Connecng Mist
Access Points and Juniper EX Series Switches.
• CLI commands
Plug and Play
EX4100 and EX4100-F switches already have factory-default sengs congured right out of the box to make them
plug-and-play devices. The default sengs are stored in a conguraon le that:
• Sets Ethernet switching and storm control on all interfaces
• Sets Power over Ethernet (PoE+) on all RJ-45 ports of models that provide PoE+
• Enables the following protocols:
• Internet Group Management Protocol (IGMP) snooping
• Rapid Spanning Tree Protocol (RSTP)
• Link Layer Discovery Protocol (LLDP)
• Link Layer Discovery Protocol-Media Endpoint Discovery (LLDP-MED)
These sengs are loaded as soon as you power on the switch. If you want to see what’s in the factory-default
conguraon le for your switch, see EX4100 and EX4100-F Default Conguraon.
Customize the Basic Conguraon Using the CLI
Have these values handy before you begin customizing sengs for the switch:
10

Juniper EX4100 Specifications

General

Model	EX4100
Category	Switch
Layer	Layer 2/3
Power Consumption	Varies by model and configuration
PoE	Optional
Management	Web UI, CLI, SNMP
Operating Temperature	0°C to 45°C
Input Voltage	100-240V AC
Storage Temperature	-40°C to 70°C
Humidity	5% to 90% non-condensing
DC Power Input	-48V DC
JUNOS OS	Yes
Security Features	ACLs
Layer 2 Features	VLAN, RSTP, MSTP, LACP
Layer 3 Features	Static routing, OSPF
QoS	8 queues per port
