RJ-45 to DB-9 serial port adapter (provided)
•
Management host, such as a PC, with an Ethernet port (not provided)
Install the Mounting Shelf in a Rack
The following table specifies the holes in which you insert cage nuts and screws to install the mounting hardware required
(an x indicates a mounting hole location). The hole distances are relative to one of the standard U divisions on the rack.
The bottom of all mounting shelves is at 0.02 in. (0.05 cm) above a U division.
Mounting ShelfDistance Above U DivisionHoles
X2.00 in. (5.1 cm) 1.14 U4
X1.51 in. (3.8 cm) 0.86 U3
X0.88 in. (2.2 cm) 0.50 U2
X0.25 in. (0.6 cm) 0.14 U1
1. If needed, install cage nuts in the holes as specified in the table.
2. On the back of each rack rail, partially insert a mounting screw into the lowest hole specified in the table.
3. Install the mounting shelf on the back of the rack rails. Rest the bottom slot of each flange on a mounting screw.
4. Insert screws into the open holes in each flange of the mounting shelf.
5. Tighten all the screws completely.
2
