ISG 2000 User’s Guide
42  Replacing Power Supplies
2. Place the ground lug on the grounding screw, and tighten the hex nut by
rotating it clockwise until it holds firmly.
Figure 30: Adding the Ground Lug
3. Connect the other end of the grounding wire to a grounding point at your site.
To connect DC power feed wires to the terminal block:
1. To open the three connectors on the terminal block so that they can receive
wire feeds, use a screwdriver to turn the retaining screws counterclockwise.
Figure 31: Opening the Connectors
Retaining Screws at Top
of Terminal Block
(viewed from above)
To open connectors,
turn retaining screws
counterclockwise.
