Chapter 13
Network Cable Specifications and
Connector Pinouts
The network interfaces supported on the router accept different kinds of network
cable.
■ Serial PIM Cable Specifications on page 223
■ Fast Ethernet RJ-45 Connector Pinout on page 233
■ Gigabit Ethernet uPIM RJ-45 Connector Pinout on page 233
■ Gigabit Ethernet ePIM RJ-45 Connector Pinout on page 234
■ Chassis Console Port Pinouts on page 234
■ E1 and T1 RJ-48 Cable Pinouts on page 235
■ E3 and T3 BNC Connector Pinout on page 238
■ ADSL and G.SHDSL RJ-11 Connector Pinout on page 238
■ ISDN RJ-45 Connector Pinout on page 239
■ Connector Pinouts for Avaya VoIP Modules on page 239
Serial PIM Cable Specifications
The 2-port serial PIM uses the cables and connectors summarized in
Table 71 on page 223. Pinouts are detailed in Table 72 on page 224 through
Table 81 on page 232.
Table 71: 2-Port Serial PIM Cables and Connectors
Pinouts
End-to-End
ConductorsConnector HardwareConnectorName
Table 72 on page 224134-40 threaded
jackscrews
DB-25 maleRS-232 DTE
Table 73 on page 225134-40 threaded jacknutsDB-25 femaleRS-232 DCE
Table 74 on page 225254-40 threaded
jackscrews
DC-37 (DB-37) maleRS-422/449 (EIA-449)
DTE
Table 75 on page 227254-40 threaded jacknutsDC-37 (DB-37) femaleRS-422/449 (EIA-449)
DCE
Serial PIM Cable Specifications ■ 223
