Juniper J-series Services Router J4350 User Manual

Table 99: TIM518 Connector Pinout (continued)
SignalPin
Tip29
Tip30
Tip31
Tip32
33
Tip42
Tip43
44
Tip45
Tip46
Tip47
Tip48
Tip49
TIM521 Connector Pinout
The TIM521 Telephony Interface Module uses an RJ-45 cable. Table 100 on page 245
describes the TIM521 RJ-45 connector pinout.
Table 100: TIM521 RJ-45 Connector Pinout
SignalPin
No connection1
No connection2
Transmit pair +3
Receive pair +4
Receive pair –5
Transmit pair –6
No connection7
No connection8
Connector Pinouts for Avaya VoIP Modules ■ 245
Chapter 13: Network Cable Specifications and Connector Pinouts
