Juniper MX2020 User Manual

Table 2: Components to Remove from the Front of the MX2020
Router (continued)
Number of FRUsSlots
Component
DescriptionComponent No.
80 through 7Switch Fabric Boards
(SFBs)
2
20 and 1Control Board and
Routine Engine
(CB-RE)
3
100 through 9MPCs with ADCs and
MICs (bottom)
4
Figure 9: Components to Remove from the Rear of an AC-Powered
MX2020 Router
D
g007081
1
10
2
3
4
5
6
7
8
9
11
Remove field replacement units (FRUs) from the rear of the MX2020 router before you
install the router. See Table 3 on page 19 for information about MX2020 router
components.
Copyright © 2015, Juniper Networks, Inc.18
MX2020 3D Universal Edge Router Quick Start
