5
SRX100
SRX210
SRX240
Specifications
Protocols
IPv4, IPv6, ISO Connectionless Network Service (CLNS)
Routing and Multicast
Static routes
RIPv2
OSPF
BGP
BGP Router Reflector
1
IS-IS
Multicast ((Internet Group Management Protocol (IGMPv3),
PIM, Session Description Protocol (SDP), Distance Vector
Multicast Routing Protocol (DVMRP), source-specific))
7
MPLS
4
IP Address Management
Static
Dynamic Host Configuration Protocol (DHCP) (client and server)
DHCP relay
Encapsulations
Ethernet (MAC and tagged)
Point-to-Point Protocol (PPP) (synchronous)
Multilink Point-to-Point Protocol (MLPPP)
Frame Relay
Multilink Frame Relay (MLFR) (FRF.15, FRF.16)
High-Level Data Link Control (HDLC)
Serial (RS-232, RS-449, X.21, V.35, EIA-530)
802.1q VLAN support
Point-to-Point Protocol over Ethernet (PPPoE)
Trac Management
Marking, policing, and shaping
Class-based queuing with prioritization
Weighted random early detection (WRED)
Queuing based on VLAN, data-link connection identifier (DLCI),
interface, bundles, or filters
Security
Firewall, zones, screens, policies
Stateful firewall, ACL filters
Denial of service (DoS) and distributed denial of service (DDoS)
protection (anomaly-based)
Prevent replay attack; Anti-Replay
Unified Access Control
UTM
2
(SRX650 and high memory versions of SRX240, SRX210,
and SRX100 only)
Antivirus
2
, antispam
2
, Web filtering
2
, IPS
2
Content Security Accelerator in SRX210 high memory, SRX240
high memory, and SRX650
2
ExpressAV option in SRX210 high memory, SRX240 high
memory, and SRX650
2
Content filtering
VPN
Tunnels (generic routing encapsulation, IP-in-IP, IPsec)
IPsec, Data Encryption Standard (DES) (56-bit), triple Data
Encryption Standard (3DES) (168-bit), Advanced Encryption
Standard (AES) (256-bit) encryption
Message Digest 5 (MD5) and SHA-1 authentication
Access Manager: Dynamic VPN Client. Browser based remote
access feature requiring a license.
Voice Transport
FRF.12
Link fragmentation and interleaving (LFI)
Compressed Real-Time Transport Protocol (CRTP)
High Availability
VRRP
Stateful failover and dual box clustering via JSRP3
SRX650:
Redundant power (optional)
Future GPIM hot swap (online insertion and removal, OIR)
Future internal failover and SRE hot swap (OIR)
Backup link via 3G wireless or other WAN
SRX650

Other manuals for Juniper SRX100

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Juniper SRX100 and is the answer not in the manual?

Juniper SRX100 Specifications

General IconGeneral
Routing protocolsBGP, IS-IS, MPLS, OSPF
Switching protocolsVLAN 802.1Q, 802.3ad/LACP, STP
Supported network protocolsIPv4, IPv6, CLNS
Firewall securityYes
Security algorithms3DES, DES
Authentication methodRADIUS, RSA SecureID, LDAP
VPN supportIPsec VPN
Data transfer rate0.1 Gbit/s
Input voltage100 - 240 V
Input frequency50/60 Hz
Heat dissipation35 BTU/h
Power requirements100-240, 50/60
Power over Ethernet (PoE)No
Power consumption (typical)30 W
SafetyUL 60950-1, CSA 60950-1, AS / NZS 60950-1, AS / NZS 60950-1, CB Scheme, EN 60950-1
CertificationFCC Class B ICES class B AS / NZS CISPR22 Class B AS / NZS CISPR22 Class B VCCI Class B EN 55022 Class B, EN 300386
Mounting typeRack mounting
Internal memory1024 MB
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Weight1100 g
Dimensions (WxDxH)216 x 147 x 36 mm
