Juniper SRX300 User Manual

Retype new password: password
Issue the commit command to activate the candidate configuration that disables ZTP:
[edit]
root# commit
4. Enable root login over SSH, and allow SSH access over the WAN interface (ge-0/0/0).
[edit]
root# set system services ssh root-login allow
root# set security zones security-zone untrust interfaces ge-0/0/0.0 host-inbound-traffic system-services ssh
5. Configure the hostname.
[edit]
root# set system host-name host_name
6. That’s it! The initial configuration is complete. Commit the configuration to activate the changes on the SRX.
[edit]
root# commit
Congratulations! Your SRX is Up and Running
Your SRX300 is now online and providing secure Internet access to devices attached to the LAN ports. You can manage
the device locally and remotely, using the Junos CLI, J-Web, or a cloud based provisioning service. Here's what your
network looks like:
9

Juniper SRX300 Specifications

General

USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	15.4 W
Noise level	0 dB
Heat dissipation	85 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	389820 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Firewall throughput	1000 Mbit/s
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	1980 g
Dimensions (WxDxH)	320.8 x 34.7 x 191 mm
