3. Plug the power cord into the SRX345 rear panel.
g000958
4. If the AC power source outlet has a power switch, turn it off.
5. Plug the other end of the power cord into the AC power source outlet.
6. If the AC power source outlet has a power switch, turn it on.
7. If you are using a SRX345 Firewall with dual AC power supplies, then repeat Step 3 through Step 5 for the second
power supply.
The SRX345 powers up as soon as you connect it to power. When the PWR and STAT LEDs on the front panel are lit
solid green, the SRX345 is ready to use.
Step 2: Up and Running
IN THIS SECTION
SRX345 Provisioning Options | 6
Initial Configuration Using the CLI | 6
Now that the SRX345 is powered on, let’s do some initial configuration to get it up and running on the network.
5

Juniper SRX345 Specifications

General

USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	8
Flash memory	8000 MB
Internal memory	4000 MB
Certification	FCC A, RoHS 2
Rack capacity	1U
Heat dissipation	420 BTU/h
Power consumption (typical)	122 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, MPLS, OSPF, RIP-1, RIP-2
Supported network protocols	IPv4, IPv6
Firewall security	Yes
Security algorithms	IPSEC, SSL/TLS
Networking standards	IEEE 802.1p
Ethernet LAN data rates	10, 100, 1000 Mbit/s

Weight and Dimensions

Weight	4900 g
Dimensions (WxDxH)	440.9 x 370.1 x 43.6 mm
