7.1.1.3. For countries with country codes: S0492 / NGLM24-4 HN S0492
7.1.1.4. For countries with country codes: S5092
lt/min kg/h
Gas type
G20_20mbar
G30_29mbar
G20_20mbar
G30_29mbar
Power (kW)
/Country code
7,3 1,2 3,0 14,2 0,7
8,5 1,6 3,0 16,5 0,7
9,5 2,0 4,0 18,5 0,8
11,0 2,5 5,0 20,7 0,8
11,9 3,1 6,3 23,0 1,0
12,6 3,4 7,7 24,4 1,1
14,4 4,3 8,5 27,8 1,1
15,6 5,0 11,0 30,0 1,3
16,8 5,7 12,8 32,3 1,4
18,0 6,4 14,6 34,5 1,5
19,2 7,2 16,6 36,8 1,6
20,4 8,0 18,7 39,0 1,7
22,0 9,1 20,9 42,0 1,7
23,2 9,9 23,9 44,2 1,9
24,0 10,6 28,5 45,7 2,0
mbar
Burner Pressure Gas flow
lt/min kg/h lt/min
Gas type
G20_20mbar G30_29mbar
G25.1_25mbar
G20_20mbar G30_29mbar G25.1_25mbar
Power (kW)
/Country code
7,3 1,2 3,0 1,0 14,5 0,7 16,8
9,5 2,0 5,1 2,0 18,0 0,9 21,5
10,7 2,5 6,4 2,6 21,2 1,0 24,2
11,9 3,1 7,8 3,1 23,5 1,1 26,9
12,6 3,4 8,7 3,6 24,8 1,1 29,5
14,4 4,4 11,2 4,5 28,2 1,3 32,2
15,6 5,0 12,9 5,2 30,5 1,4 34,9
16,8 5,7 14,8 6,0 32,7 1,5 37,6
18 6,5 16,8 6,9 35,0 1,6 40,3
19,2 7,2 18,9 7,7 37,2 1,7 43,0
20,4 8,0 21,1 8,7 39,4 1,8 45,6
21,6 8,8 23,4 9,8 41,5 1,8 48,3
22,9 9,7 26,0 11,0 43,9 2,0 51,0
24 10,7 28,5 12,1 46,0 2,0 53,7
Burner Pressure Gas flow
mbar
6 720 660 238 (2008/07)
57
| 57Gas Setting Values
