Hangzhou Junce Instruments Co., Ltd.
Voltage and Current Limit Function Introduction:
The upper and lower limit of the voltage and current is to set the upper
and lower limit of the voltage and current adjustment. For example: set 30V,
5A on the main interface, enter the voltage and current upper limit saving
location, and press OK to save them as the voltage and current upper limit.
The maximum voltage adjustment range of the product is 30V and the
maximum current is 5A. The same method can be used to set the lower
adjustment limit.
Communication Protocol Function:
There are two kinds of communication protocols: simple communication
protocol and MODBUS communication protocol, which can be selected on the
product. Communication protocols are provided by our company.
Simple communication protocol is our custom communication protocol. It
is easy to understand.
MODBUS communication protocol is the standard MODBUS
communication protocol.
Quick Discharge Function Introduction:
After the fast discharge is turned on, when the voltage is turned from high
to low, the response time is relatively short.
For example: 30V is being output, and the output is directly adjusted to
5V. When fast discharge is not turned on, it takes 5 seconds to drop from 30V
to 5V, but if the fast discharge is turned on, it takes less than 1 second to drop
from 30V to 5V.
Power-on Default State Settings:
The power-on default state refers to whether the output is turned on or off
by default when the power is turned on. When this function is turned on, the
Press the button shortly to
enter the baud rate selection
interface. There are 7 groups of
baud rates in Kbps. Use the
or button to change the baud
rate, and then press the
button. The setting is finished.
Press the button shortly to enter
the communication address selection
interface. There are a total of 99
communication addresses from 01 to
99. Change the communication
addresses by pressing the or
button, and then press .The
setting is finished.
To Next Page
