SPARE PART DATA SHEET – LC 420 D
REV. 12
10-12-2021
24 / 44
Jurop SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
TEL. +39 0434 636811 FAX. +39 0434 636812
http://www.jurop.it
e-mail: info@jurop.it
LC 420 DIRECT TRANSMISSION
Pos.
Code
Description
Q.ty
Pos.
Code
Description
Q.ty
1
1401200700
OIL DRIPPER
2
50
4022300001
OIL FILTER
1
2
1407200800
WATER PUMP RIGHT (LC D RIGHT)
1
51
4023100047
BEARING 6309 C3
1
1407200900
WATER PUMP LEFT (LC D LEFT)
1
52
4023110051
BEARING NU 309 ECJ/C3
1
3
1521505900
ROTOR LC420
1
53
4024251000
OIL PUMP CW ROTATION (LC D R)
1
1521505700
ROTOR LC420 USA
1
4024251500
OIL PUMP CCW ROTATION (LC D L)
1
4
154201TVB0
BELT PROTECTION LC D RIGHT
1
54
4025350019
BELT SPZ 925
1
154201TWB0
BELT PROTECTION LC D LEFT
1
55
4026101301
SCREW TE 8.8 M6X10 ZINC.
2
5
1601606300
VANE LC 420
4
56
4026102806
SCREW TE 8.8 M8X20 ZINC.
7
6
1605500100
HANDLE
1
57
4026102807
SCREW TE 8.8 M8X25 ZINC.
16
7
1608100000
DISTRIBUTOR
1
58
4026102808
SCREW TE 8.8 M8X30 ZINC.
3
8
1608502500
CONVEYOR
1
59
4026102819
SCREW TE 8.8 M8X90 ZINC.
2
9
1610051700
FLANGE
1
60
4026102908
SCREW TE 8.8 M10X30 ZINC.
18
10
1610508200
FLANGE
1
61
4026103030
SCREW TE 8.8 M12X16 ZINC.
4
11
1610512900
OIL PUMP FLANGE
1
62
4026121303
SCREW TCEI 8,8 M6X12 ZINC.
4
12
1610513500
FLANGE
2
63
4026121304
SCREW TCEI 8,8 M6X14 ZINC.
2
13
161201X4B0
PUMP SUPPORT
1
64
4026121710
SCREW TCEI 8.8 M12X35 ZINC.
2
14
1622002600
SHAFT M10
1
65
4026135415
GRUB SCREW 14.9 M8X50 ZINC.
1
14A
4026414617
PIN 3X40 (LC LEFT ROTATION)
1
66
4026135504
GRUB SCREW 14.9 M10X10 ZINC.
1
15
1623100500
CONVEYOR FLANGE
1
67
4026171211
STUD SCREW 8,8 M12X80 ZINC.
2
16
1624037700
SPACER
2
68
4026305618
SELF-LOCKING NUT M12 ZINC.
2
17
1624042800
SPACER
2
69
4026308005
NUT M8 ZINC.
2
18
162409YKB0
SPACER
1
70
4026308006
NUT M10 ZINC.
2
19
1624202300
4 WAYS SPACER
1
71
4026350503
WASHER GROWER M6
4
20
16275007E0
MANIFOLD
1
72
4026350508
WASHER GROWER M12
2
21
16401008E0
CLAPET COVER
1
73
4026350706
WASHER GROWER M8
22
22
1642100200
REAR PROTECTION
1
74
4026350708
WASHER GROWER M10
4
23
165351TXB0
DRIVEN PULLEY
1
75
4026351504
WASHER M6
4
24
166301STB0
LUBRICATION LINE FLANGE
1
76
4026351505
WASHER M8
6
25
166301SWB0
LUBRICATION LINE OIL TANK R
1
77
4026351506
WASHER M10
16
166303QWB0
LUBRICATION LINE OIL TANK R USA
1
78
4026357005
WASHER M8
2
166301SXB0
LUBRICATION LINE OIL TANK L
1
79
4026357006
WASHER M10
4
166303QXB0
LUBRICATION LINE OIL TANK L USA
1
80
4026357007
WASHER M12
2
26
166301SZB0
LUBRICATION LINE HOUSING-FLANGE
1
81
4026359001
WASHER 40X33.5X1.5 AL
6
27
166301T0B0
LUBRICATION LINE HOUSING-FLANGE
1
82
4026359006
WASHER 13.5X18X1.5 AL
4
28
166301T1B0
LUBRICATION LINE FLANGE
1
83
4026501008
TAB 12X8X70
1
29
1663062600
DISCHARGE SHORT LUBRICATION LINE R
1
4026500912
TAB 10X8X70 (USA)
1
166301T5B0
DISCHARGE SHORT LUBRICATION LINE L
1
84
4026510032
SEEGER E45
2
30
1663062700
DISCHARGE LONG LUBRICATION LINE R
1
85
4026702000
FITTING 4X1/8
6
166301T8B0
DISCHARGE LONG LUBRICATION LINE L
1
86
4026706000
FITTING 90° 4X1/8
4
31
1673001000
OIL FILTER PLUG
1
87
4026706003
FITTING 90° 6X1/8
2
32
1680609700
OIL PUMP GASKET
1
88
4026706101
ADJUSTABLE FITTING
2
33
1680610200
MANIFOLD GASKET
2
89
4026904003
PLUG 1”
6
34
16807011E0
CLAPET COVER GASKET
1
90
4026904300
VENTIL PLUG ¼”
2
35
1680707300
FRONT FLANGE GASKET
2
91
4026904503
PLUG M20X1.5
1
36
1680707800
CONVEYOR FLANGE GASKET
1
92
4026905002
PLUG ¼”
2
37
1680709700
FLANGE GASKET
1
93
4026910103
PLUG
1
38
1680709800
PUMP HOUSING GASKET
2
94
4026910601
PLUG 1/8
2
39
1681100200
OIL DRIPPER FLANGE
1
95
4029602701
NUT M8 PROTECTION
1
40
1685002800
WASHER 30X8,5X4
1
41
1685100000
OIL DRIPPER WASHER 14X20X1,5
2
189207X2B0
GASKET KIT LC 420
1
42
1685100300
WASHER DI 20
2
43
1687508200
LC 420 HOUSING PUMP
1
44
1687600000
OIL TANK
1
45
1691000000
SPRING
1
46
18930008E0
CLAPET D.110 INOX WITH OR
1
47
4022200030
Y-SEAL 41X27X10
1
48
4022200044
Y-SEAL 65X45X8
1
49
4022200416
Y-SEAL 60X75X8
4
