2.1. Dimensions
Versions with hydraulic motor / smooth shaft
PUMP LUBRICATION
HOUSING
CS: tank filling point
OL: oilers
CL: vanes wear checking
A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
LC 300
250
290
290
442
601,5
436
285,5
60
86
135
253
205
182
654
76-80
Ø 90
95
LC 420
250
290
290
442
645
469
277,5
60
77
152,5
279
205
249,5
789
80-100
Ø 90
95
LC 580
300
340
400
456
645
469
281,5
60
77
152,5
279
210
212,5
827
80-100
Ø 90
95
LC 750
300
340
400
463
662,5
473
281,5
74
77
200
403,5
210
232,5
931
120
Ø104
110
O HDR
P HDR
LC 300
428
970
LC 420
494
1098
LC 580
462
1141
LC 750
492
1192
Versions with gear box (540 -1000 RPM)
A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
LC 300
250
290
290
442
601,5
436
285,5
84
86
135
253
83
262
805
76-80
Ø 90
95
45
LC 420
250
290
290
442
645
469
277,5
84
77
152,5
279
83
331
934,5
80-100
Ø 90
95
45
LC 580
300
340
400
456
645
469
281,5
84
77
152,5
279
83
299
979
80-100
Ø 90
95
30
LC 750
300
340
400
463
662,5
473
281,5
81
77
200
403,5
93
319
1017,5
120
Ø104
110
30
PUMP LUBRICATION
CS: tank filling point
OL: oilers
HOUSING
CL: vanes wear checking
GEARBOX
LM: oil level
CM: inlet plug
SM: outlet plug
