jurop LC 420 User Manual

INSTALLATION, USE AND MAINTENANCE MANUAL – LC
REV. 12
10-12-2021
3 / 44
Jurop SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
TEL. +39 0434 636811 FAX. +39 0434 636812
http://www.jurop.it
e-mail: info@jurop.it
Contents
1.
General warnings
pag.
4
1.1
Introduction
4
1.2
Spare part request
4
1.3
Warranty terms and conditions
4
2.
Technical data
pag.
5
2.1
Dimensions
6
2.3
Performances
7
2.4
Noise power
8
2.5
Usage Limitations
8
2.6
Lubrication
8
3.
Safety and accident prevention
pag.
9
3.1
General recommendations
9
3.2
Intended use
9
3.3
Conveyed fluids
9
4.
Installation
pag.
10
4.1
Checking upon receipt
10
4.2
Storing in the warehouse
10
4.3
Handling and installation
10
4.4
Mounting
10
4.5
Vacuum – Pressure line
11
4.6
Cooling system
11
4.7
Overheating alarm (optional)
12
4.8
Vacuum-pressure inverter:
Remote control actuators
12
4.9
Pump mounting - Drive connection
13
5.
Start up
pag.
14
5.1
Starting-up of the pump
14
5.2
Precautions when starting the system
15
5.3
Precautions of use
15
6.
Maintenance
pag.
16
6.1
Ordinary maintenance
16
6.2
Extraordinary maintenance
17
7.
Malfunctions: troubleshooting
pag.
20
8.
Scrapping
pag.
20
9.
Accessories
pag.
21
SPARE PART DATA SHEET – LC 300-420-580 D
24
SPARE PART DATA SHEET – LC 300-420-580, M 540/1000
28
SPARE PART DATA SHEET – LC 300-420-580 HYD
30
SPARE PART DATA SHEET – LC HYD, LUBRICATION PIPE
31
SPARE PART DATA SHEET – LC 750 D
32
SPARE PART DATA SHEET – LC 750 M
34
SPARE PART DATA SHEET – LC 750 HYD
36
SPARE PART DATA SHEET – COOLING WATER PUMP LC
37
SPARE PART DATA SHEET – ACCESSORIES
38
