SPARE PART DATA SHEET – LC 750 D
REV. 12
10-12-2021
33 / 44
Jurop SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
TEL. +39 0434 636811 FAX. +39 0434 636812
http://www.jurop.it
e-mail: info@jurop.it
LC 750 DIRECT TRANSMISSION
Pos.
Code
Description
Q.ty
Pos.
Code
Description
Q.ty
1
1401200700
OIL DRIPPER
2
56
4022200113
SEAL RING SEAL RING 70X55X15
2
2
1407200900
WATER PUMP CCW ROTATION (LC D LEFT)
1
57
4022300001
FILTER (NYLON)
1
1407200800
WATER PUMP CW ROTATION (LC D RIGHT)
1
58
4023115059
BEARING NJ 309 ECJ/C3-NMQ
2
3
154201TUB0
PROTECTION WATER PUMP (LC D LEFT)
1
59
4023130035
BUSHING 55X45X22
2
154201TSB0
PROTECTION WATER PUMP (LC D RIGHT)
1
60
4024251000
AUTOMATIC LUBRICAT. PUMP CW ROTATION
1
4
16016003E0
VANE LC750
5
4024251500
AUTOMATIC LUBRICAT. PUMP CCW ROTAT.
1
5
1605500100
HANDLE
1
61
4025350020
BELT
1
6
1608100000
DISTRIBUTOR
1
62
4025426003
BUSHING
1
7
1608502600
CONVEYOR
1
63
4025426209
PULLEY
1
8
16105014E0
FLANGE DIRECT TRANSMISSION
2
64
4026102702
SCREW TE M6X12 ZINC.
2
9
1610508200
FLANGE
1
65
4026102806
SCREW TE M8X20 ZINC.
6
10
1610512900
AUTOMATIC LUBRICATION PUMP FLANGE
1
66
4026102819
SCREW TE M8X90 ZINC.
1
11
161201X4B0
BRACKET
1
67
4026102904
SCREW TE M10X16 ZINC.
2
12
16120617H0
OIL DRIPPER PLATE BRACKET
1
68
4026102908
SCREW TE M10X30 ZINC.
2
13
1613501400
OIL PUMP BRACKET
1
69
4026103003
SCREW TE M12X35 ZINC.
16
14
16215063E0
ROTOR
1
70
4026121305
SCREW TCEI M6X16 ZINC.
2
15
1622002600
OIL PUMP SHAFT
1
71
4026121401
SCREW TCEI M8X12 ZINC.
2
16
1623100600
CONVEYOR CAP
1
72
4026121406
SCREW TCEI M8X30 ZINC.
2
17
1624037500
SPACER
1
73
4026121407
SCREW TCEI M8X25 ZINC.
18
18
162403N3B0
SPACER (REAR PROTECTION)
1
74
4026121710
SCREW TCEI M12X35 ZINC.
6
19
1624042800
SPACER (OIL TANK)
2
75
4026135415
GRUB SCREW M8X50 ZINC.
1
20
162409YKB0
SPACER (SPRING)
1
76
4026171211
STUD SCREW M12X80 ZINC.
2
21
1624202300
SPACER (4-WAY VALVE)
1
77
4026300025
COMPENSATION RING
2
22
1626001100
BUSHING DIRECT TRANSMISSION
2
78
4026305508
SELF-LOCKING NUT M12
2
23
16275005E0
MANIFOLD
1
79
4026308005
NUT M8
2
24
16401004E0
CLAPET CAP
1
80
4026308006
NUT M10
2
25
1642100200
REAR PROTECTION
1
81
4026350503
WASHER GROWER 6
2
26
16500087E0
REAR SHAFT
1
82
4026350505
WASHER GROWER 8
23
27
16500089E0
SHAFT
1
83
4026350508
WASHER GROWER 12
22
28
16631154E0
PIPE (FRONT FLANGE – HOUSING)
1
84
4026350705
WASHER GROWER 6
2
29
16631155E0
PIPE (OIL DRIPPER – REAR FLANGE)
1
85
4026350706
WASHER GROWER 8
4
30
16631156E0
PIPE (REAR FLANGE – HOUSING)
1
86
4026350708
WASHER GROWER 10
4
31
16631157E0
PIPE (FRONT FLANGE – HOUSING)
1
87
4026357005
WASHER M8
2
32
16631158E0
PIPE (SUCTION, RIGHT)
1
88
4026357006
WASHER M10
6
33
16631160E0
SHORT PIPE (OIL PUMP – OIL DRIPPER R)
1
89
4026359001
WASHER 33.5X40X1.5
6
16631163E0
SHORT PIPE (OIL PUMP – OIL DRIPPER L)
1
90
4026359005
WASHER 12X16X1.5
2
34
16631161E0
LONG PIPE (OIL PUMP – OIL DRIPPER R)
1
91
4026501007
TAB 12X8X63
1
16631164E0
LONG PIPE (OIL PUMP – OIL DRIPPER L)
1
92
4026702000
FITTING
4
35
1672001600
SCREW TCEI M10X1,5
10
93
4026702708
WASHER 1"1/2
1
36
1673001000
FITTING
1
94
4026706000
FITTING 90° 4X1/8
6
37
1680612200
GASKET (CONVEYOR CAP)
1
95
4026706003
FITTING 90° 6X1/8
2
38
16807006E0
GASKET (CLAPET CAP)
1
96
4026706101
ADJUSTABLE FITTING
2
39
16807007E0
GASKET (SUCTION)
1
97
4026904003
PLUG 1"
6
40
16807008E0
GASKET (DISCHARGE)
1
98
4026904005
PLUG 1"1/2
1
41
16807043E0
FLANGE GASKET (HOUSING)
2
99
4026904300
VENTIL PLUG 1/4
2
42
1680707300
FRONT FLANGE GASKET (DIRECT TR.)
1
100
4026910103
VENTIL PLUG
1
43
1680710000
FLANGE GASKET (BRACKET)
1
101
4026910601
PLUG 1/8'
2
44
1685002800
WASHER 30X8.5
1
102
4029602701
NUT M8 CAP
1
45
1685100000
OIL DRIPPER WASHER 14X20X1.5
2
46
1685100300
WASHER
1
18920110E0
GASKET KIT LC750
1
47
1685100800
WASHER 8X14X1.5
2
48
16875042E0
HOUSING LC750
1
49
1687600000
OIL TANK
1
50
1691000000
SPRING
1
51
18930006E0
CLAPET DN125
1
52
4022100107
GREASER
1
53
4022200008
SEAL RING 90X45X8
1
54
4022200030
SEAL RING 41X27X10
1
55
4022200044
SEAL RING 65X45X8
1
