SPARE PART DATA SHEET – LC 750 M
REV. 12
10-12-2021
35 / 44
Jurop SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
TEL. +39 0434 636811 FAX. +39 0434 636812
http://www.jurop.it
e-mail: info@jurop.it
LC 750 WITH GEARBOX
Pos.
Code
Description
Q.ty
Pos.
Code
Description
Q.ty
1
1401200700
OIL DRIPPER
2
53
1685100800
WASHER 8X14X1.5
1
2
1407200900
WATER PUMP CCW ROTATION (LC M LEFT)
1
54
16875042E0
HOUSING LC750
1
1407200800
WATER PUMP CW ROTATION (LC M RIGHT)
55
1687600000
OIL TANK
1
3
154201TUB0
PROTECTION WATER PUMP (LC M LEFT)
1
56
1691000000
SPRING
1
154201TSB0
PROTECTION WATER PUMP (LC M RIGHT)
57
18930006E0
CLAPET DN125
1
4
16016003E0
VANE LC750
5
58
4022100107
GREASER
1
5
1605500100
HANDLE
1
59
4022200008
SEAL RING 90X45X8
1
6
1608100000
DISTRIBUTOR
1
60
4022200030
SEAL RING 41X27X10
1
7
1608502600
CONVEYOR
1
61
4022200040
SEAL RING 72X40X10
1
8
16105014E0
FLANGE
1
62
4022200113
SEAL RING 70X55X15
2
9
16105015E0
FLANGE
1
63
4022300001
FILTER (NYLON)
1
10
1610512900
AUTOMATIC LUBRICATION PUMP FLANGE
1
64
4023100020
BEARING 6207
1
11
161201X4B0
WATER PUMP BRACKET
1
65
4023100039
BEARING 6308/C3
1
12
16120617H0
OIL DRIPPER BRACKET
1
66
4023115059
BEARING NJ 309 ECJ/C3-NMQ
2
13
1613501400
OIL PUMP BRACKET
1
67
4023130035
BUSHING 55X45X22
2
14
16215063E0
ROTOR
1
68
4024251000
AUTOMATIC LUBRICAT. PUMP CW ROTATION
1
15
1622002600
OIL PUMP SHAFT
1
4024251500
AUTOMATIC LUBRICAT. PUMP CCW ROTAT.
16
1623100600
CONVEYOR CAP
1
69
4025350020
BELT
1
17
1624037500
SPACER
1
70
4025426003
BUSHING
1
18
162403N3B0
SPACER (REAR PROTECTION)
1
71
4025426209
PULLEY
1
19
1624042800
SPACER (OIL TANK)
2
72
4026102702
SCREW TE M6X12 ZINC.
2
20
162409YKB0
SPACER (SPRING)
1
73
4026102804
SCREW TE M8X16 ZINC.
3
21
1624202300
SPACER (4-WAY VALVE)
1
74
4026102806
SCREW TE M8X20 ZINC.
3
22
1626001100
BUSHING DIRECT TRANSMISSION
1
75
4026102810
SCREW TE M8X40 ZINC.
8
23
16275005E0
MANIFOLD
1
76
4026102819
SCREW TE M8X90 ZINC.
1
24
16401004E0
CLAPET CAP
1
77
4026102904
SCREW TE M10X16 ZINC.
2
25
164059V5B0
GEARBOX CAP
1
78
4026102908
SCREW TE M10X30 ZINC.
2
26
1642100200
REAR PROTECTION
1
79
4026103003
SCREW TE M12X35 ZINC.
14
27
16500087E0
REAR SHAFT
1
80
4026121305
SCREW TCEI M6X16 ZINC.
2
28
16500090E0
SHAFT
1
81
4026121401
SCREW TCEI M8X12 ZINC.
2
29
1651005300
PINION Z 25 (540 RPM)
1
82
4026121406
SCREW TCEI M8X30 ZINC.
2
165109KFB0
PINION Z 37 (1000 RPM)
83
4026121407
SCREW TCEI M8X25 ZINC.
18
30
165109KEB0
GEAR Z 53 (540 RPM)
1
84
4026121709
SCREW TCEI M12X30 ZINC.
2
165109KGB0
GEAR Z 41 (1000 RPM)
85
4026121710
SCREW TCEI M12X35 ZINC.
6
31
16631155E0
PIPE (OIL DRIPPER – REAR FLANGE)
1
86
4026135415
GRUB SCREW M8X50 ZINC.
1
32
16631156E0
PIPE (REAR FLANGE – HOUSING)
1
87
4026155505
SCREW TSPEI M5X16 ZINC.
4
33
16631158E0
PIPE (SUCTION R)
1
88
4026171211
STUD SCREW M12X80 ZINC.
2
34
16631160E0
SHORT PIPE (OIL PUMP – OIL DRIPPER R)
1
89
4026300025
COMPENSATION RING
2
16631163E0
SHORT PIPE (OIL PUMP – OIL DRIPPER L)
1
90
4026305508
SELF-LOCKING NUT M12
2
35
16631161E0
LONG PIPE (OIL PUMP – OIL DRIPPER R)
1
91
4026306115
SELF-LOCKING NUT M36X3
1
16631164E0
LONG PIPE (OIL PUMP – OIL DRIPPER L)
1
92
4026308005
NUT M8
2
36
16631162E0
PIPE (OIL DRIPPER – HOUSING)
1
93
4026308006
NUT M10
2
37
1672001600
SCREW TCEI M10X1,5
10
94
4026350503
WASHER GROWER 6
2
38
1673001000
FITTING
1
95
4026350505
WASHER GROWER 8
20
39
1680612200
GASKET (CONVEYOR CAP)
1
96
4026350508
WASHER GROWER 12
20
40
16807006E0
GASKET (CLAPET CAP)
1
97
4026350705
WASHER GROWER 6
2
41
16807007E0
GASKET (SUCTION)
1
98
4026350706
WASHER GROWER 8
12
42
16807008E0
GASKET (DISCHARGE)
1
99
4026350708
WASHER GROWER 10
4
43
16807043E0
FLANGE GASKET (HOUSING)
2
100
4026356002
WASHER 8X24
3
44
1680710000
FLANGE GASKET (BRACKET)
1
101
4026357005
WASHER M8
2
45
16807BCNB0
GASKET (GEARBOX)
1
102
4026357006
WASHER M10
6
46
1681006500
PLATE
1
103
4026359001
WASHER 33.5X40X1.5
6
47
1684000000
DRAIN PLUG 3/8
3
104
4026359005
WASHER 12X16X1.5
2
48
1685002800
WASHER 30X8.5
1
105
4026401806
PIN 10X36
4
49
1685100000
OIL DRIPPER WASHER 14X20X1.5
2
106
4026501004
TAB 12X8X45
1
50
1685100200
WASHER 17X22X1.5
1
107
4026702000
FITTING
2
51
16851002E0
WASHER 12X18X1.5
2
108
4026702708
WASHER 1"1/2
1
52
1685100300
WASHER
1
109
4026706000
FITTING 90° 4X1/8
6
