jurop R260 User Manual

R
EV
.
0
1
23-02-2017
INSTALLATION , USE AND MAINTENANCE MANUAL – R 260
16 / 24
Jurop
SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
T
EL
.
+
39
0
434
636811
F
AX
.
+39
0
434
636812
http://www.jurop.it
e-mail: info@jurop.it
PROBLEMS
Cause Solution
•
Faulty lubrication
•
Check the oil pump
•
Missing oil
•
Fill up the oil tank
•
Re
volutions to high
•
Reduce the
speed
•
Operating time too long at too high vacuum rate
•
Decrease the vacuum rate
• Clogged filters on the air injection system
•
Clean the filters
• Insufficient diameter of vacuum and discharge line
•
Check the correct
dimensions of the line (minimum suggested 3”)
Cause Solution
•
Brocken vanes
:
•
Dismantle the pump and change the vanes
-
due to foreign parts
•
Check/clean the filters and elements on the vacuum line
-
due to faulty lubr
ication
•
Check the lubrication pump
•
Damaged drive system
•
Change the damaged parts
•
Frozen up pump
•
Warm
-
up the pump
Cause Solution
• 4
-
way valve handle in neutral position
• Move the handle against the resting pin
•
Worn vanes
•
Change the vanes
•
Leaking check valve
•
Clean the check valve
•
Worn O
-
rings
•
Change the seals
• Leaking gaskets and/or valves on the vacuum tank
•
Change that damaged parts
•
Clogged connecting pipeline
• Change the damaged hoses
-
p
ipes
• Floating ball or air filter obstructed
•
Dismantle and clean
•
Crusted up exhaust manifold
•
Dismantle and clean
• Vacuum line components under
-
dimensioned
• Check the dimensioning for the pump model at hand
• Rubber connection obstructed or dam
aged
•
Change the connections
Cause Solution
•
Insufficient lubrication
• Adjust the oil pump flow
• Excessive oil consumption
• Loss of adjustment of the oil pump
• Probable wear or breakage of the seal rings of the vacuum pump shaft.
Replace them
• Check the fittings built on the automatic oil pump and screw tight
• Recycling materials allow reducing the environmental impact and
respecting the environment.
Do not dispose of in the environment. Dispose of
in compliance with the standards in force.
• Before scrapping the machine, the following materials need to be
separated and suitably disposed of
Material Cast Iron Steel Alluminum Copper Bronze Rubber Vanes Oil Plastic
R 260 91 % 7 % 0,3 % 0,2 % 0,1 % 0,1 % 0,8 % 0,3 % 0,2 %
Anomalo consumo d’olio
Riduzione delle prestazioni
Il compressore non gira
Overheating
8.
Scrapping
7
.
Malfunctions: troubleshooting
