SPARE PART DATA SHEET – R 260
18 / 24
Jurop
SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
T
EL
.
+
39
0
434
636811
F
AX
.
+39
0
434
636812
http://www.jurop.it
e-mail: info@jurop.it
R 260
Pos.
Code Description Q.ty Pos.
Code Description Q.ty
1 1493300200 AIR INJECTION VALVE 1/2'' 2 53 4022300001 FILTER 1
2 1521500900 ROTOR R 260 1 54 4022301001 OIL BLOCK FILTER ¼ 1
3 1601604200 VANE 5 55 4022301004 OIL BLOCK FILTER ¾ 2
4 1605500000 HANDLE 1 56 4023100140 BEARING 6308 2
5 16081001E0 DISTRIBUTOR 1 57 4024251500 OIL PUMP (RIGHT) 1
6 1608503100 CONVEYOR 1 4024251000 OIL PUMP (LEFT) 1
7 1610006600 FLANGE 1 58 4026102702 SCREW TE M6X12 2
8 1610500400 FLANGE 1 59 4026102704 SCREW TE M6X16 ZINC. 4
9 1610508500 OIL PUMP FLANGE 1 60 4026102806 SCREW TE M8X20 10
10 16105E5BB0 FLANGE 1 61 4026102807 SCREW TE M8X25 3
11 16120816F0 PLATE 1 62 4026102907 SCREW TE M10X25 16
12 16120820E0 PLATE 2 63 4026102911 SCREW TE M10X45 ZINC. 4
13 1612500300 OIL TANK 1 64 4026103000 SCREW TE M12X20 ZINC. 4
14 1622002600 OIL-PUMP DRIVE PIN 1 65 4026121305 SCREW TCEI M6X16 ZINC. 2
15 1623100800 COCK MANIFOLD 1 66 4026121407 SCREW TCEI M8X25 ZINC. 16
16 162409YKB0 SPACER 1 67 4026135414 SCREW M8X45 1
17 1624202300 SPACER 1 68 4026135504 SCREW M10X10 1
18 16275008E0 MANIFOLD 1 69 4026300020 COMPENSATION RING 2
19 1640101100 CAP 1 70 4026305614 NUT 1
20 16401098E0 CAP 1 71 4026308005 NUT M8. 2
21 1642003000 PROTECTION 1 72 4026350505 WASHER GROWER 8 ZINC. 15
22 1642600000 PROTECTION 2 73 4026350708 WASHER GROWER 10 ZINC. 4
23 1650004300 FRONT SMOOTH SHAFT 1 74 4026350709 WASHER GROWER 12 ZINC. 4
1650004700 FRONT SPLINED SHAFT 1 75 4026351504 WASHER M 6 ZINC. 2
24 1663014000 PIPE 2 76 4026351505 WASHER M 8 ZINC. 13
25 16630254E0 PIPE 1 77 4026351506 WASHER M10 ZINC. 16
16630259E0 PIPE 1 78 4026357003 WASHER M6 ZINC. 4
26 16630255E0 PIPE 1 79 4026414617 PIN 3X40 1
16630261E0 PIPE 1 80 4026500018 TAB 6X10 1
27 16630256E0 PIPE 1 81 4026701301 FITTING 1/2X18 2
16630260E0 PIPE 1 82 4026702004 FITTING 6X1/8 5
28 16630257E0 PIPE 1 83 4026706000 FITTING 90°4X1/8 2
16630262E0 PIPE 1 84 4026706003 FITTING 90° 6X1/8 2
29 16630258E0 PIPE 1 85 4026706101 FITTING 4-1/8 2
16630263E0 PIPE 1 86 4026740011 FITTING G1/4 1
30 1663041200 PIPE 1 87 4026905002 PLUG 1/4 1
31 1673004100 OIL DIP-STICK SLEEVE 1 88 4027409920 ONE-WAY VALVE G1/4 1
32 1680609700 GASKET 1
33 1680609800 GASKET 1
34 1680700200 GASKET 1
35 1680700400 GASKET 1
36 16807020E0 GASKET 1
37 16807021E0 GASKET 1
38 16807022E0 GASKET 1
39 1680707500 GASKET 1
40 1683600300 ASTA LIVELLO 1
41 1684000000 TAPPO SCARICO 3/8 4
42 1685002800 RONDELLA FE 30X8,5 SP.4 1
43 1685100000 RONDELLA OLIAT 14X20X1,5 1
44 1685100200 RONDELLA PIANA 17X22X1,5 4
45 16875026E0 OIL STICK 1
46 1691000000 SPRING 1
47 18930009E0 CLAPET 1
48 4022100107 GREASER 1
49 4022200030 SEAL 41X27X10 1
50 4022200111 SEAL 72X48X15 3
51 4022200313 OR 2162 1
52 4022200341 OR 4825 2
