S PARE PART DATA SHEET – RV360 - A CCESSORIES
R
EV
.
0
9
21-03-2016
23 / 32
Jurop
SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
T
EL
.
+39
0
434
636811
F
AX
.
+39
0
434
636812
http://www.jurop.it
e-mail: info@jurop.it
RV 360 Accessories
Pos.
Code Description Q.ty Pos.
Code Description Q.ty
1 1852108600 FIXED SUCTION CONVEYOR Ø80 KIT 9 143028B7B0 PNEUMAT. OPERATED 4-WAY VALVE KIT
C1 1627100300 SUCTION CONVEYOR Ø80 1 P1 160858KNB0 PNEUMATIC ACTUATOR COCK 1
C2 4022200307 OR 6287 VIT. 1 P2 161258B4B0 PNEUMATIC ACTUATOR SUPPORT 1
C3 4026103002 SCREW TE M12X30 UNI5739 GALV. 2 P3 1640580QB0 PNEUMATIC ACTUATOR COVER 1
C4 4026350709 WASHER GROWER 12 FLAT SEC. GALV. 2 P4 167007ZAB0 PNEUMATIC ACTUATOR NUT 1
2 1852108900 FIXED SUCTION CONVEYOR Ø76 KIT P5 1680700200 COVER GASKET 1
C1 1627100200 SUCTION COVEYOR Ø76 1 P6 168409PQB0 COCK REGULATION FERRULE 1
C2 4022200307 OR 6287 VIT. 1 P7 168529TFB0 COCK REGULATION SPACER 1
C3 4026103002 SCREW TE M12X30 UNI5739 GALV. 2 P8 1691000200 COCK SPRING 1
C4 4026350709 WASHER GROWER 12 FLAT SEC. GALV. 2 P9 4022100100 SPHERICAL GREASER M6X1 1
3 1852109000 TURNING CONVEYOR Ø76 KIT P10 4022200005 SEAL 37X27X7 1
C5 1610100000 CONVEYOR FLANGE 1 P11 4022200330 OR 3375 1
C6 1627100500 CONVEYOR Ø76 1 P12 4022200331 OR 2137 1
C7 4022200307 OR 6287 VIT. 1 P13 4026102804 SCREW TE M8X16 UNI5739 ZINC. 4
C8 4026103002 SCREW TE M12X30 UNI5739 GALV. 2 P14 4026102807 SCREW TE M8X25 UNI5739 ZINC. 4
C9 4026350709 WASHER GROWER 12 FLAT. SEC. GALV. 2 P15 4026121405 SCREW TCEI M8X20 UNI5931 ZINC. 4
4 1852111600 FLANGE 2” ½ NPT KIT P16 4026350505 WASHER GROWER 8 GALV. 4
F1 1610101400 FLANGE 2” ½ NPT 1 P17 4026351505 WASHER M8 ZINC. 8
F2 1680614500 MANIFOLD GASKET 1 P18 4027100405 PNEUMATIC ACTUATOR 1
F3 4026121711 SCREW TCEI 8,8 M12X40 GALV. 2 P19 4027421206 CONNECTION R15 6XG1/8 2
F4 4026350508 WASHER GROWER 12 GALV. 2 10 HYDRAULIC DRIVE
5 18521CNGB0 SUCTION FILTER KIT H1 1470106700 HDR RV COUPLING 1
6 FLANGED MANIFOLD H2 1610052300 HDR RV FLANGE COUPLING 1
F1 1627505500 FLANGED MANIFOLD 1 H3 1612501000 HDR MOTOR MOUNTING FLANGE 1
F2 1680611400 DISCHARGE SIDE MANIFOLD GASKET 1 H4 1617015500 TAB RV360-520 HDR 1
F3 1680611500 SUCTION SIDE MANIFOLD GASKET 1 H5 16171001E0 SQUARE HDR 1
F4 4026102807 SCREW TE 8,8 M8X25 UNI5931 GALV. 12 H6 1622010200 RV CONVEYOR DOWEL PIN 4
F5 4026135504 SCREW 12,9 M10X10 GALV. 1 H7 1624042300 HDR RV COUPLING SEAL SPACER 2
F6 4026350706 WASHER GROWER 8 FLAT SEC. GALV. 12 H8 1627105200 RV CONVEYOR WITH SUPPORT 2
7 THREADED MANIFOLD H9 1642008400 CONVEYOR WITH SUPPORT PROTECTION 2
F2 1680611400 DISCHARGE SIDE MANIFOLD GASKET 1 H10 4022200011 SEAL A 64X80X8 NBR 2
F3 1680611500 SUCTION SIDE MANIFOLD GASKET 1 H11 4024107009 RV360 HYDRAULIC MOTOR 1
F4 4026102807 SCREW TE 8,8 M8X25 GALV. 12 H12 4026103004 SCREW TE 8,8 M12X40 UNI5739 GALV. 4
F5 4026135504 SCREW 12,9 M10X10 GALV. 1 H13 4026103111 SCREW TE 8,8 M14X45 GALV. 4
F6 4026350706 WASHER GROWER 8 GALV. 12 H14 4026121409 SCREW TCEI 8,8 M8X40 UNI5931 GALV. 3
F7 1627505600 THREADED MANIFOLD 1 H15 4026121713 SCREW TCEI 8,8 M12X80 UNI5931 GALV. 2
8 143029K2B0 KIT HYDRAULIC ACTUATOR H16 4026121719 SCREW TCEI 8,8 M10X60 UNI5931 GALV. 4
I1 143027T6B0 CILINDER 1 H17 4026121815 SCREW TBEI 10,9 M10X15 GALV. 8
I2 150206XXB0 LEVER 1 H18 4026122005 SCREW 12,9 M8X12 8
I3 151309JVB0 BASE 1 H19 4026136005 SCREW 12,9 M8X20 1
I4 1608503200 MANIFOLD 1 H20 4026136009 SCREW TCEI 8,8 M8X40 UNI5931 GALV. 1
I5 1623100800 COVER 1 H21 4026171203 SCREW 8,8 M12X40 GALV. 2
I6 16240A0IB0 SPACER 1 H22 4026305508 SELF-LOCKING NUT M12 4
I7 1624202300 SPACER 1 H23 4026350505 WASHER GROWER 8 GALV. 6
I8 164206XYB0 ACTUATOR PROTECTION 1 H24 4026350506 WASHER GROWER 10 GALV. 8
I9 1680700200 GASKET 1 H25 4026350508 WASHER GROWER 12 GALV. 8
I10 1685002800 WASHER FE 30X8,5 SP.4 GALV. 1 H26 4026350709 WASHER GROWER 12 FLAT SEC. GALV. 4
I11 168509U0B0 WASHER 1 H27 4026350710 WASHER GROWER 14 FLAT SEC. GALV. 4
I12 1691000000 SPRING 1 H28 4026357006 FLAT WASHER M10 GALV. 8
I13 4022100100 GREASER M6X1 1 H29 4026359001 WASHER 40X33,5X1,5 1
I14 4022100107 GREASER 45 1 H30 4026510040 SEEGER E63 UNI7435-30 2
I15 4022200030 SEAL 41X27X10 1 H31 4026711003 SAE G1’’1/4 FLANGE 1
I16 4026120405 SCREW TCEI M8X25 4 H32 4026711004 SAE G1’’1/2 FLANGE 1
I17 4026121405 SCREW TCEI M8X20 GALV. 2 H33 4026904003 PLUG G1 GALV. 1
I18 4026135414 SCREW M8X45 ZINC. 1 11 1892006300 COMPLETE JOINT KIT RV HDR 1
I19 4026155705 SCREW TSPEI M8X16 GALV. 1
I20 4026308005 NUT M8 ESAG.GALV. 4
I21 4026350505 WASHER GROWER 8 GALV. 6
I22 4026510012 SEEGER E14 1
