S PARE PART DATA SHEET – RV520 - A CCESSORIES
R
EV
.
0
9
21-03-2016
27 / 32
Jurop
SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
T
EL
.
+39
0
434
636811
F
AX
.
+39
0
434
636812
http://www.jurop.it
e-mail: info@jurop.it
RV 520 Accessories
Pos.
Code Description Q.ty Pos.
Code Description Q.ty
1 1852103400 FIXED SUCTION CONVEYOR Ø80 KIT 10 143028GZB0 PNEUM. OPERATED 4-WAY VALVE KIT
C1 1627101300 SUCTION CONVEYOR Ø80 1 P1 160858KBB0 PNEUMATIC ACTUATOR COCK 1
C2 4022200310 OR 6362 VIT. 1 P2 161258H0B0 PNEUMATIC ACTUATOR SUPPORT 1
C3 4026102807 SCREW TE M8X25 GALV. 4 P3 1640580QB0 PNEUMATIC ACTUATOR COVER 1
C4 4026350706 WASHER GROWER 8 FLAT SEC. GALV. 4 P4 167007ZAB0 PNEUMATIC ACTUATOR NUT 1
P5 1680707800 COVER GASKET 1
2 1852103500 FIXED SUCTION CONVEYOR Ø100 KIT P6 168409PQB0 COCK REGULATION FERRULE 1
C1 1627101200 SUCTION CONVEYOR Ø100 1 P7 168529TFB0 COCK REGULATION SPACER 1
C2 4022200310 OR 6362 VIT. 1 P8 1691000200 COCK SPRING 1
C3 4026102807 SCREW TE M8X25 GALV. 4 P9 4022100100 SPHERICAL GREASER M6X1 1
C4 4026350706 WASHER GROWER 8 FLAT SEC. GALV. 4 P10 4022200005 SEAL 37X27X7 1
P11 4022200330 OR 3375 1
3 1852103900 TURNING CONVEYOR Ø80 KIT P12 4022200331 OR 2137 1
C5 1610101100 CONVEYOR FLANGE 1 P13 4026102804 SCREW TE M8X16 UNI5739 GALV. 4
C6 1627102700 CONVEYOR Ø80 1 P14 4026102807 SCREW TE M8X25 UNI5739 GALV. 4
C7 4022200310 OR 6362 VIT. 1 P15 4026121405 SCREW TCEI M8X20 UNI5931 GALV. 4
C8 4026102808 SCREW TE M8X30 UNI5739 GALV. 4 P16 4026350505 WASHER GROWER 8 GALV. 4
C9 4026350706 WASHER GROWER 8 FLAT SEC. GALV. 4 P17 4026351505 WASHER M8 ZINC. 8
P18 4027100405 PNEUMATIC ACTUATOR 1
4 1852104000 TURNING CONVEYOR Ø100 KIT P19 4027421206 CONNECTION R15 6XG1/8 2
C5 1610101100 CONVEYOR FLANGE 1
C6 1627102400 CONVEYOR Ø100 1 11 143029KRB0 KIT HYDRAULIC ACTUATOR
C7 4022200310 OR 6362 VIT. 1 I1 143027T6B0 CILINDER 1
C8 4026102808 SCREW TE M8X30 UNI5739 GALV. 4 I2 15020A10B0 LEVER 1
C9 4026350706 WASHER GROWER 8 FLAT SEC. GALV. 4 I3 1513007TJB0 BASE 1
I4 1608502900 MANIFOLD 1
5 1852104100 KIT FOR SAFETY VALVE I5 1623100700 COVER 1
S1 1627102500 SAFETY VALVE G2 SUPPORT 1 I6 162409YKB0 SPACER 1
S2 4022200310 OR 6362 VIT. 1 I7 1624043400 SPACER 1
S3 4026102807 SCREW TE 8,8 M8X25 UNI5739 GALV. 4 I8 1624202300 SPACER 1
S4 4026102810 SCREW TE 8,8 M8X40 UNI5739 GALV. 4 I9 164206XYB0 ACTUATOR PROTECTION 1
S5 4026308005 NUT M8 UNI5588 GALV. 4 I10 1673009700 GREASER LINK 1
S6 4026350706 WASHER GROWER 8 FLAT SEC. GALV. 8 I11 1680707800 GASKET 1
I12 1685002800 WASHER 30X8,5 GALV. 1
6 1852111700 FLANGE 3” NPT KIT I13 168509U0B0 WASHER 1
F1 1610101500 FLANGE 3” NPT 1 I14 1691000000 SPRING 1
F2 1680709900 MANIFOLD GASKET 1 I15 4022100100 GREASER M6X1 1
F3 4026102808 SCREW TCEI 8,8 M8X30 GALV. 4 I16 4022100107 GREASER 45ø M10X1 1
F4 4026350706 WASHER GROWER 8 GALV. 4 I17 4022200030 SEAL 41X27X10 1
I18 4026121408 SCREW TCEI M8X25 4
7 185212L4B0 SUCTION FILTER KIT COMPONENTS I19 4026121405 SCREW TCEI M8X20 GALV. 2
I20 4026135414 SCREW M8X45 1
8 FLANGED MANIFOLD I21 4026155705 SCREW TSPEI M8X16 1
F1 1627504800 FLANGED MANIFOLD 1 I22 4026308005 NUT M8 HEXAG. GALV. 4
F2 1680610200 MANIFOLD GASKET 2 I23 4026350505 WASHER GROWER 8 GALV. 6
F3 4026135504 SCREW 12,9 M10X10 GALV. 1 I24 4026510012 ELASTIC SEAL E14 1
F4 4026350706 WAHER GROWER 8 FLAT SEC. GALV. 12
F5 4026102807 SCREW TE 8,8 M8X25 UNI5931 GALV. 12
9 THREADED MANIFOLD
F2 1680610200 MANIFOLD GASKET 2
F3 4026135504 SCREW 12,9 M10X10 GALV. 1
F4 4026350706 WASHER GROWER 8 FLAT SEC. GALV. 12
F5 4026102807 SCREW TE 8,8 M8X25 UNI5931 GALV. 12
F6 1627504900 THREADED MANIFOLD 1
