S PARE PART DATA SHEET – RV520 - A CCESSORIES
28 / 32
Jurop
SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
T
EL
.
+39
0
434
636811
F
AX
.
+39
0
434
636812
http://www.jurop.it
e-mail: info@jurop.it
Pos.
Code Description Q.ty Pos.
Code Description Q.ty
12 HYDRAULIC DRIVE H17 4026121815 SCREW TCEI 8,8 M10X60 GALV. 6
H1 1470106700 HDR RV COUPLING 1 H18 4026122005 SCREW TBEI 10,9 M10X15 GALV. 8
H2 1610052300 HDR RV FLANGE COUPLING 1 H19 4026136005 SCREW 12,9 M8X12 1
H3 1612501000 HDR MOTOR MOUNTING FLANGE 1 H20 4026136009 SCREW 12,9 M8X20 1
H4 1617015500 TAB RV360-520 HDR 1 H21 4026171203 SCREW 8,8 M12X40 GALV. 2
H5 16171001E0 SQUARE HDR 1 H22 4026305508 SELF-LOCKING NUT M12 4
H6 1622010200 RV CONVEYOR DOWEL PIN 4 H23 4026350505 WASHER GROWER 8 GALV. 6
H7 1624042300 HDR RV COUPLING SEAL SPACER 2 H24 4026350506 WASHER GROWER 10 GALV. 6
H8 1627105200 RV CONVEYOR WITH SUPPORT 2 H25 4026350508 WASHER GROWER 12 GALV. 10
H9 1642008400 CONVEYOR WITH SUPPORT PROTECTION 2 H26 4026350709 WASHER GROWER 12 GALV. 4
H10 4022200011 SEAL A 64X80X8 NBR 2 H27 4026350710 WASHER GROWER 14 GALV. 4
H11 4024107001 RV520 HYDRAULIC MOTOR 1 H28 4026357006 FLAT WASHER M10 UNI6592 GALV. 8
H12 4026103004 SCREW TE 8,8 M12X40 GALV. 2 H29 4026359001 WASHER 40X33,5X1,5 1
H13 4026103111 SCREW TE 8,8 M14X45 GALV. 4 H30 4026510040 SEEGER E63 UNI7435-30 2
H14 4026121409 SCREW TCEI 8,8 M8X40 GALV. 3 H31 4026904003 PLUG G1 GALV. 1
H15 4026121713 SCREW TCEI 8,8 M12X50 GALV. 2
H16 4026121719 SCREW TCEI 8,8 M12X80 GALV. 6 13 1892006300 COMPLETE JOINT KIT RV HDR 1
