jurop RV520 User Manual

I NSTALLATION , USE AND MAINTENANCE MANUAL – RV360 - 520
R
EV
.
0
9
21-03-2016
3 / 32
Jurop
SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
T
EL
.
+39
0
434
636811
F
AX
.
+39
0
434
636812
http://www.jurop.it
e-mail: info@jurop.it
Contents
1. General warnings
pag. 4
1.1 Introduction 4
1.2 Spare part request 4
1.3 Warranty terms and conditions 4
2. Technical data
pag. 5
2.1 Dimensions and arrangement RV 360-520 5
2.2 Dimensions and arrangement accessories 7
2.3 Performances 8
2.4 Usage Limitations 8
2.5 Lubrication 8
3. Safety and accident prevention
pag. 9
3.1 General recommendations 9
3.2 Intended use 9
4. Installation
pag. 9
4.1 Checking upon receipt 10
4.2 Storing in the warehouse 10
4.3 Mounting 11
4.4 Vacuum – pressure line 11
4.5 Hydraulic actuator adjustment 11
4.6 Pneumatic actuator adjustment 11
4.7 Pump mounting - Drive connection 12
5. Start up
pag. 13
5.1 Starting-up of the pump 13
5.2 Precautions when starting the system 13
5.3 Precautions of use 13
6. Maintenance
pag. 14
6.1 Ordinary maintenance 14
6.2 Extraordinary maintenance 15
7.
Malfunctions:
troubleshooting
pag. 19
8. Scrapping
pag. 19
S PARE PART DATA SHEET – RV 360 20
S PARE PART DATA SHEET – RV 360 - ACCESSORIES 22
S PARE PART DATA SHEET – RV 520 24
S PARE PART DATA SHEET – RV 520 - ACCESSORIES 26
9.
Cooling fans installation
instructions
pag. 29
