SPECIFICATIONS
Z14R SPECIFICATION
Energiser Output Voltage 9.5kV peak no load
Peak Output Energy 4 Joules at 500 Ohms, Limited to
2.5 Joules in Group Mode
Pulse Rate Locked at 0.8 Hz
12v Dc Power Consumption Energiser on – 550mA average,
700mA peak
Energiser o – 28mA (40mA
with keypad)
Not including keypad or auxil-
iary power
Ac Power Input 16-18Vac
Battery Charger Output Float voltage 14V, 500mA, short
circuit and reverse polarity pro-
tection utilising 3A slow SMD
fuses.
Siren and Strobe Outputs Self-resetting fuse protection,
switched 12V, rated at 30W
(combined)
Switched outputs Three 30V 1A “Form C” change-
over contacts
Enclosure IP4x ABS plastic
Size 300mm high, 190mm wide,
115mm deep
Weight – packed, no battery 1.9kg
