JVA Z14/Z14R User Manual
Z14 SPECIFICATION
Energiser Output Voltage 9.5kV peak no load
Peak Output Energy 5 Joules at 500 Ohms
Pulse Rate Locked at 0.8 Hz
12v Dc Power Consumption Energiser on – 550mA average,
876mA peak
Energiser o – 16mA (28mA with
keypad)
Not including keypad or auxil-
iary power
Ac Power Input 16-18Vac
Battery Charger Output Float voltage 14V, 500mA, short
circuit and reverse polarity pro-
tection utilising 3A slow SMD
fuses.
Siren and Strobe Outputs Self-resetting fuse protection,
switched 12V, rated at 30W
(combined)
Enclosure IP4x ABS plastic
Size 300mm high, 190mm wide,
115mm deep
Weight – packed, no battery 1.9kg
Z14 Specicaons
