Page 14
© JVA Technologies Pty. Ltd.
Electric Fencing Products
Command Key1 Key2 Keys 3 and 4 Key5
Relay 3 (Z14R only) 2 3 Options Explained under “1.3.1 Relay Functions” Default is 00 #
Relay 4 (Z14R only) 2 4 Options Explained under “1.3.1 Relay Functions” Default is 02 #
Relay 5 (Z14R only) 2 5 Options Explained under “1.3.1 Relay Functions” Default is 07 #
Group Mode 2 6 00 01 02 etc 15 #
No Group Master Slave 1 Slave 14
Exit Programming Mode * #
Programming Commands
1.3.1
Keys 3
and 4
Funtion Description
00 Fence Triggers when Zone 1 is Armed and Return Voltage is below the Threshold Voltage
01 Fence or O Triggers when Zone 1 is Disarmed or Return Voltage is below the Threshold Voltage
02 Armed Zone 1 is Armed
06 Fence Bi-Polar Triggers when energiser is Armed and the fence Return Voltage on either Bi-Polar return
line has fallen below the Threshold Voltage
