JVC AV-21VS21 - TV Buttons and Parts

24
TV buttons and parts
4 531 2 7 8 9 0
8 7 9 0
1
3 645
2
12345
9
0
7
8
-
1 Headphone jack
2 VIDEO-3 terminal
3 MENU button
4 CHANNEL m buttons
5 VOLUME m buttons
6 TV/VIDEO button
7 ECO sensor
8 Remote control sensor
9 POWER lamp
0 Main power button
- SUB POWER lamp
<AV-21YX11 only>
When the main power is switched on, the
POWER lamp turns red.
When the TV is turned on (the sub power
is on), the SUB POWER lamp turns green.
<AV-29VS21/AV-29WS21/AV-29VX71/AV-29WX11>
<AV-21YX11>
<AV-21VS21/AV-21VX71/AV-25VS21/AV-25VX71>
<AV-21WS21/AV-21WX11>
4
5
3
1
2
7 8
9
0
