JVC DLA-RS15 - Controls and Features

1
Getting started
12

Front Side/Left Side

Rear Side/Top Side/Right Side
Controls and features
To connect the power cord (
P24
)
Remote Sensor (
P15
)
Lamp Cover (
P48
)
Exhaust Vent
Remote Sensor
(
P15
)
Air Inlet
Lens Cover (opened)
(
P24
)
Lens Cover
(closed)
CAUTION

Do not place your fingers in the gap at the lens
during lens shift adjustment. This may cause injuries

(
P25
)


between the lens cover while closing the cover. This
can cause injuries or malfunction.
