JVC DT-R17L4DU - Dimensions

25
EN
Dimensions
Unit: mm (inch)
DT-R24L4D
<Front view> <Side view> <Rear view>
564 (22 1/4)
300 (11 7/8)
408 (16 1/8)
413.1 (16 3/8)
99 (4)
51.9 (2 1/8)
181(7 1/4)
1.5 (1/8)
21 (7/8)
100
VESA mounting holes
(Size: M4, depth: 10 mm)
100117
(4 5/8)
To install the monitor on a shelf To install the monitor on a wall
<Top view> <Side view> <Rear view> <Side view>
270 (10 3/4)
111.3
(4 1/2)
210 (8 3/8)
160 (6 3/8)
30.3
(1 1/4)
36.7 (1 1/2)
10-φ8
14.3
(5/8)
179 (7 1/8)
23.5 (1)
160 (6 3/8)
215 (8 1/2)
67
(2 3/4)
60
(2 3/8)
6-φ8
15
(5/8)
70
(2 7/8)
70
(2 7/8)
64.5
(2 5/8)
88.2
(3 1/2)
DT-R17L4D
<Front view> <Side view> <Rear view>
430 (17)
309 (12 1/4)
314.1 (12 3/8)
300 (11 7/8)
18 (3/4)
102 (4 1/8)
56 (2 1/4)
1.3 (1/16)
181 (7 1/4)
3 (1/8)
100
VESA mounting holes
(Size: M4, depth: 10 mm)
100115
(4 5/8)
To install the monitor on a shelf To install the monitor on a wall
<Top view> <Side view> <Rear view> <Side view>
270 (10 3/4)
114.3
(4 5/8)
210 (8 3/8)
160 (6 3/8)
30.3 (1 1/4)
36.7 (1 1/2)
10-φ8
17.3
(5/8)
179 (7 1/8)
23.5 (1)
15
160 (6 3/8)
165 (6 1/2)
(2 3/4)
60
(2 3/8)
14.5
67
6-φ8
70
(2 7/8)
70
(2 7/8)
(5/8)
(5/8)
88.2
(3 1/2)
