Available signals
The following signals are available for this monitor.
Video signals
No. Signal name
Signal format shown in
the status display
(☞ page 11)
Input terminal
VIDEO
(INPUT1, INPUT2)
E. AUDIO HD/SD SDI
(IN 1, IN 2)*
1
DVI-D (HDCP)
(Digital component
/Digital RGB)
1 NTSC NTSC
√
——
2 PAL PAL
√
——
3 B/W50 B/W50
√
——
4 B/W60 B/W60
√
——
5 480/60i 480/60i —
√√
6 480/59.94i 480/59.94i —
√√
7 576/50i 576/50i —
√√
8 480/60p 480/60p — —
√
9 480/59.94p 480/59.94p — —
√
10 576/50p 576/50p — —
√
11
640*480/60p 640*480/60p
——
√
12
640*480/59.94p 640*480/59.94p
——
√
13 720/60p 720/60p —
√√
14 720/59.94p 720/59.94p —
√√
15 720/50p 720/50p —
√√
16 720/30p 720/30p —
√
—
17 720/29.97p 720/29.97p —
√
—
18 720/25p 720/25p —
√
—
19 720/24p 720/24p —
√
—
20 720/23.98p 720/23.98p —
√
—
21 1080/60i 1080/60i —
√√
22 1080/59.94i 1080/59.94i —
√√
23 1035/60i 1035/60i —
√√*
2
24 1035/59.94i 1035/59.94i —
√√*
3
25 1080/50i 1080/50i —
√√
26 1080/60p 1080/60p — —
√
27 1080/59.94p 1080/59.94p — —
√
28 1080/50p 1080/50p — —
√
29 1080/30p 1080/30p —
√√
30 1080/29.97p 1080/29.97p —
√√
31 1080/25p 1080/25p —
√√
32 1080/24p 1080/24p —
√√
33 1080/23.98p 1080/23.98p —
√√
34 1080/30psF 1080/30psf —
√*
2
—
35 1080/29.97psF 1080/29.97psf —
√*
3
—
36 1080/24psF 1080/24psf —
√
—
37 1080/23.98psF 1080/23.98psf —
√
—
√: Acceptable
—: Not acceptable
*
1
Compatible with EMBEDDED AUDIO signals.
*
2
The signal is recognized as 1080/60i, and the status is displayed as “1080/60i.”
*
3
The signal is recognized as 1080/59.94i, and the status is displayed as “1080/59.94i.”
