䡵 IF-C01HSDG: HD SDI INPUT CARD
Type : HD SDI input card for Multi-Format Monitor
Inputs/Outputs : Digital input (HD SDI 1/HD SDI 2): 2 lines, BNC connector x 2 (0.8 V (p-p), 75 Ω)
Digital output (SWITCHED OUT): 1 line, BNC connector x 1 (0.8 V (p-p), 75 Ω)
Audio signal: 1 line (monaural), RCA pin x 2 (0.5 V (rms), high impedance)
* The input (IN) and output (OUT) terminals are bridge-connected.
Format : HD serial component digital, BTAS-004B SMPTE292M (Digital Interface Standard)
Required slots :1
Power consumption : 14 V DC, 0.72 A
Weight : 0.7 kg
Dimensions
(W x H x D) : 43 mm x 154.5 mm x 200.2 mm
䡵 IF-C12HSDG: HD SDI INPUT CARD
Type : HD SDI input card for Multi-Format Monitor
Inputs/Outputs : Digital input (HD SDI 1/HD SDI 2): 2 lines, BNC connector x 2 (0.8V (p-p), 75 Ω)
(compliant with AES/EBU EMBEDDED AUDIO)
Digital output (HD SDI 1/HD SDI 2): 2 lines, BNC connector X 2 (0.8V (p-p), 75 Ω)
Format : HD serial component digital, BTAS-004B, SMPTE292M (Digital Interface Standard),
SMPTE299M (AES/EBU EMBEDDED AUDIO)
Required slots : 1
Power consumption : 14 V DC, 0.6A
7 V DC, 0.6A
Weight : 0.7 kg
Dimensions
(W x H x D) : 43 mm x 154.5 mm x 191.9 mm
SPECIFICATIONS (INPUT CARD: OPTIONAL)
(cont’d)
