13
EN
7 Stereo Microphone
8 Grip Strap ( p. 18)
9 HDMI Connector [HDMI] ( p. 33)
: DC Connector [DC] ( p. 16)
; Microphone Input Connector [MIC]
< LED Light
= USB Connector [
2
]
> Remote Sensor ( p. 11)
? Lens Cover/Lens
@ Shoe (for external microphone, etc)
A Shoe Cover
B Lens Cover Switch [
=
,
>
] ( p. 18)
C microSD Card Slot ( p. 19)
D Tripod Mounting Socket ( p. 18)
E Battery Release Button [BATT.] ( p. 16)
F Battery Pack Mount
Remote Control
Q Infrared Beam Transmitting Window
R ZOOM (T/W) Buttons
(Zoom in/out during playback.)
S Up Button
Rotate Button (counterclockwise)
T Skip Backward Button
U Left Button
V Back Button
W PLAYLIST Button
X START/STOP Button
Y SNAPSHOT Button
Z INFO Button
a Skip Forward Button
b PLAY/PAUSE Button
c Right Button
d Next Button
e Down Button
Rotate Button (clockwise)
f INDEX Button
g DISP Button
NOTE
You can move the zooming area with the up/
down/left/right button during zoom in playback
mode.
Camera
! Index Button [INDEX] ( p. 31)/
Remaining Space Button/
Data Battery Button [ 0 / 1 ] ( p. 22)
# Set Lever
Move to ¡ :
Reverse Skip ( p. 28)/Up/Backlight
Compensation Button [ - ] ( p. 25)
Move to ¢ :
Forward Skip ( p. 28)/Down/Manual
Focus Button [FOCUS] ( p. 24)
Move to £ :
Reverse Search ( p. 28)/Left/Light
Button [LIGHT] ( p. 22)
Move to ¤ :
Forward Search ( p. 30)/Right/Program
AE Button [PROGRAM AE] ( p. 24)
Press down:
Play/Pause ( p. 28)
$ Menu Button [MENU]
% LCD Monitor
& Speaker
( Fan outlet
) Access Lamp [ACCESS] (Blinks when you
access fi les. Do not turn off the power or
remove the battery pack/AC adapter while
accessing fi les.)
Power/Charge Lamp [POWER/CHARGE]
(Blinks when you charge the battery.)
* Zoom Lever [W 7 , T
,
] ( p. 22)
Speaker Volume Control [–VOL+] ( p. 28)
+ Still Image Shooting Button [SNAPSHOT]
( p. 21)
, Auto/Manual Mode Button [AUTO] ( p. 24)/
Information Button [INFO] ( p. 37)
- Power Button (You can turn off the camera
by pressing and holding this button.)
. Direct Disc Button [DIRECT DISC]/
Focus Assist Button [FOCUS ASSIST]
( p. 25)
/ Fan inlet
0 Direct Backup Button [DIRECT BACK UP]/
Quick Review Button [QUICK REVIEW]
( p. 20, 21)
1 Delete Button [
*
]
2 Playback/Recording Mode Switching Button
[PLAY/REC] ( p. 20, 21)
3 Audio/Video Connector [AV] ( p. 34, 47)
4 Component Connector [COMPONENT]
( p. 33)
5 Mode Switch [!, #]
6 Video Recording Start/Stop Button [START/
STOP] ( p. 20)
