1-2 (No.MB376)
SPECIFICATION
Designs and Specifications are subject to change without notice.
General Power source AC 120 V , 60 Hz
Power consumption 25 W (in operation)
1.0 W (on standby)
Weight 2.7 kg (6.0 lbs)
External dimensions (Wx H × D) 150 mm × 152 mm × 246 mm (5 15/16 in. × 6 in. × 9 11/16 in.)
DVD player Playable discs DVD VIDEO, DVD AUDIO, VCD, SVCD, CD, CD-R/RW (CD, VCD, MP3, WMA,
JPEG format), DVD-R/-RW (video format)
Video output Color system NTSC
Horizontal resolution 500 lines
Composite × 1 1.0 V (p-p)/75 Ω, synchronization negative
S-video × 1 Y output: 1.0 V (p-p)/75 Ω, synchronization negative
C output: 0.286 V (p-p)/75 Ω
Component × 1 Y output: 1.0 V (p-p)/75 Ω
PB/PR output: 0.7 V (p-p)/75 Ω
Audio output Analog sound output Speakers × 2
Output power 18 W per channel, min. RMS, at 4 Ω at 1 kHz with no more than 10% total harmonic
distortion
Fitting impedance 4 Ω to 16 Ω
Headphones × 1 11 mW/32 Ω
Fitting impedance 16 Ω to 1 kΩ
Subwoofer × 1 500 mVrms/10 kΩ
Digital sound output
Optical × 1 -21 dBm to -15 dBm
Audio input Sound input AUX x1: 400 mV/50 kΩ
Tuner FM tuner Receiving frequency: 87.5 MHz to 108.0 MHz
Antenna: 75 Ω- Unbalanced type
AM tuner Receiving frequency: 530 kHz to 1 710 kHz
Antenna: External antenna jack (loop antenna)
Speaker Type Full range
Speaker 1-way bass-reflex type
Magnetically shielded type
8cm (3 3/16 inches) cone × 1
Frequency response 60 to 20 000 Hz
Power handling capacity 20 W
Impedance 4Ω
Sound pressure level 81 dB/W m
Dimension (W × H × D) 120 mm × 150 mm × 188 mm (43/4 in. × 515/16 in. × 77/16 in.)
Weight (1 unit) 1.5 kg (3.4 lbs)
