JVC GR-D750AS - Controls; Connectors; Indicators

EN 9
GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
Controls
11 : Left/Rewind (1) ( pg. 19)/
Quick Review [QUICK REVIEW] ( pg. 16)
2 : Right/Fast-Forward (¡) ( pg. 19)
3 : Up/Play/Pause (6) ( pg. 19)/
Manual Focus [FOCUS] ( pg. 26)
4 : Down/Stop (7) ( pg. 19)/
Backlight Compensation [ ] ( pg. 28)/
Spot Exposure ( pg. 28)
Press down : SET
216:9 Wide Screen Button [16:9] ( pg. 15)
Blank Search [BLANK] ( pg. 20)
3Menu Button [MENU] ( pg. 22)
4Data Battery Button [DATA] ( pg. 13)
5Auto Button [AUTO] ( pg. 18)
6Dioptre Adjustment Control ( pg. 14)
7Snapshot Button [SNAPSHOT] ( pg. 26)
8Power Zoom Lever [T/W] ( pg. 17)
Speaker Volume Control [VOL. +, –]
( pg. 19)
9Recording Start/Stop Button [START/STOP]
( pg. 16)
!Power Switch [REC, PLAY, OFF]
"Lock Button
#Battery Release Button [BATT.] ( pg. 12)
$Cassette Open/Eject Switch [OPEN/EJECT]
( pg. 15)
Connectors
%Digital Video Connector [DV IN/OUT]
(i.LINK*) ( pg. 32, 33)
* i.LINK refers to the IEEE1394-1995 industry
specification and extensions thereof. The
logo is used for products compliant with the
i.LINK standard.
&S-Video Output Connector [S] ( pg. 21)
The connectors are located beneath the
covers.
(Audio/Video Output Connector [AV]
( pg. 21)
)DC Input Connector [DC] ( pg. 12)
Indicators
à POWER/CHARGE Lamp ( pg. 12)
Other Parts
â LCD Monitor ( pg. 8)
ä Viewfinder ( pg. 14)
ã Battery Pack Mount ( pg. 12)
å Shoulder Strap Eyelet ( pg. 11)
ç Grip Strap ( pg. 11)
é Speaker ( pg. 19)
è Lens
ê Camera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
ë Stereo Microphone
í Stud Hole ( pg. 14)
ì Tripod Mounting Socket ( pg. 14)
î Cassette Holder Cover ( pg. 15)
ï Connector Cover
Power Switch Position
REC:
To perform recording on the tape.
OFF:
To switch off the camcorder.
PLAY:
To play back a recording on the tape.
