EN 83
SPECIFICATIONS
CAMCORDER
General
Power : DC 6.3 V (using AC Adapter)
DC 7.2 V
(using Battery)
Power consumption : 6.2 W (viewfinder on), 7.0 W (LCD monitor on)
Format : DV Format (SD mode)
Signal format : NTSC Standard
Video signal recording format : Digital Component Recording
Cassette : MINI DV Cassette
Tape Speed : SP: 18.8 mm/sec.
LP: 12.5 mm/sec.
Maximum recording time : SP: 60 min.
LP: 90 min. (using DVM-60 cassette)
Pickup : 1/3" CCD
Lens : F1.6, f = 4.5 to 45 mm, 10:1 Power Zoom Lens
Filter diameter : ø27 mm
LCD monitor : 2.5", 180,000 pixel polysilicon TFT/LCD panel
Viewfinder : 0.55" color LCD
Operating temperature : 0 to 40°C (32°F to 104°F)
Operating humidity : 35 to 80%
Storage temperature : –20 to 50°C (–4°F to 122°F)
Dimensions : 49 (W) x 131 (H) x 93 (D) mm (2" x 5-3/16" x 3-11/16")
Weight : Approx. 590 g (incl. cassette and battery) (1.3 lbs)
Video
Output : 1 Vp-p, 75 Ω unbalanced, analog output
(via ø3.5 mm AV output jack)
Audio
Output : –8 dBs, 1 kΩ analog output
(via ø3.5 mm AV output jack)
Headphone : stereo
(via ø3.5 mm AV output jack)
External microphone input : –62 dBs, high impedance unbalanced with
ø3.5 mm (STEREO)
Speaker : 20 mm round x 1, monaural
AC ADAPTER/CHARGER
Power : U.S.A. and Canada : AC 120 V`, 60 Hz
Other Countries : AC 110 to 240 V`, 50/60 Hz
Power consumption : 20 W
Output power : DC 7.2 V
, 0.75 A (charge)
: DC 6.3 V
, 1.8 A (VTR)
Operating temperature : 0°C to 40°C (when charging, 10°C to 35°C)
Dimensions : 94 mm (W) x 36 mm (H) x 122 mm (D)
(3-3/4" x 1-7/16" x 4-13/16")
Weight : Approx. 310 g (0.7 lbs)
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications
subject to change without notice.
