JVC GR-DVX44 User Manual

EN87
Controls
1 E-MAIL CLIP REC Button
(GR-DVX88/DVX77 only) .................... 墌 pg. 61
2 D. SOUND PLAY Button
(GR-DVX88/DVX77 only) .................... 墌 pg. 56
3 •MENU Wheel [+, –, PUSH] ............... 墌 pg. 38
•LCD Monitor Brightness
Control [+, –] .................................... 墌 pg. 18
4 •Power Zoom Lever [T/W] .................. 墌 pg. 19
•Speaker Volume Control
[VOL.] ............................................... 墌 pg. 21
5 Power Switch
[ , , , OFF] ............................ 墌 pg. 16
6 Lock Button ......................................... 墌 pg. 16
7 Recording Start/Stop Button ................. 墌 pg. 18
8 Snapshot Button
[SNAPSHOT] ............... 墌 pg. 26, 27, 50, 59, 60
9 •FOCUS Button .................................. 墌 pg. 51
•BLANK Button ................................... 墌 pg. 24
0 Battery Release Switch
[BATT. RELEASE] .................................... 墌 pg. 8
! OPEN/EJECT Switch ............................. 墌 pg. 12
@ SELECT Button
(GR-DVX88/DVX77 only) ............... 墌 pg. 30, 32
# JUMP Button
(GR-DVX88/DVX77 only) .................... 墌 pg. 30
$ INDEX Button
(GR-DVX88/DVX77 only) .............. 墌 pg. 30, 56
% •Play/Pause Button [4/6] .................. 墌 pg. 21
•NIGHT-SCOPE Button ....................... 墌 pg. 45
^ •Fast-Forward Button [3] ............... 墌 pg. 21
•PROGRAM AE Button ....................... 墌 pg. 46
& •Stop Button [5] ................................. 墌 pg. 21
•BACKLIGHT Button ........................... 墌 pg. 52
* •Rewind Button [2] ....................... 墌 pg. 21
•EXPOSURE Button ............................. 墌 pg. 52
( VIDEO/DSC Switch [VIDEO, ]
(GR-DVX88/DVX77 only) .................... 墌 pg. 16
) CARD OPEN Switch
(GR-DVX88/DVX77 only) .................... 墌 pg. 14
q Dioptre Adjustment Control ................. 墌 pg. 10
Connectors
The connectors w to r are located beneath a cover.
w Digital Video Connector
[DV IN/OUT: GR-DVX88,
DV OUT: GR-DVX77/DVX44]
(i.link*) ..................................... 墌 pg. 58, 74, 75
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
e •Audio/Video Output Connector
[AV OUT] .............................. 墌 pg. 22, 57, 70
•Headphone Connector [ ]
(GR-DVX88/DVX77 only) .................. 墌 pg. 66
r DC Input Connector [DC IN] ............. 墌 pg. 8, 9
Indicators
t Tally Lamp ..................................... 墌 pg. 18, 40
y Power Lamp ................................... 墌 pg. 16, 18
u CHARGE Lamp ...................................... 墌 pg. 8
Other Parts
i LCD Monitor .................................. 墌 pg. 18, 19
o Battery Pack/Jack Box Mount ........... 墌 pg. 8, 23
p Speaker ................................................ 墌 pg. 21
Q Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
W Stereo Microphone .............................. 墌 pg. 66
E Flash (GR-DVX88/DVX77 only) ........... 墌 pg. 54
R Flash Sensor (GR-DVX88/DVX77 only)
Be careful not to cover this area, as it contains a
sensor required by the flash.
T Lens
Y Lens Protector
When using an optional lens filter (commercially
available), you must first detach the lens
protector.
U Remote Sensor ..................................... 墌 pg. 62
I Grip Strap ............................................ 墌 pg. 10
O Viewfinder ........................................... 墌 pg. 10
P Viewfinder Cleaning Hatch .................. 墌 pg. 84
a Memory Card Cover
(GR-DVX88/DVX77 only) .................... 墌 pg. 14
s Cassette Holder Cover ......................... 墌 pg. 12
d Tripod Mounting Socket ....................... 墌 pg. 10
