EN99
For Connectors
AV
Video output :1 V
(
p-p
)
, 75 Ω, analogue
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
Headphone output
(GR-DVX88/DVX77 only) : Stereo
DV
Input/output
(GR-DVX88 only) : 4-pin, IEEE 1394 compliant
Output
(GR-DVX77/DVX44 only) : 4-pin, IEEE 1394 compliant
AC Adapter AP-V10EG
Power requirement : AC 110 V to 240 V`, 50 Hz/60 Hz
Output : DC 11 V , 1 A
Dimensions (W x H x D) : 59 mm x 31 mm x 84 mm
Weight : Approx. 140 g (not including Power Cord)
Jack Box
For General
Dimensions (W x H x D) : 52 mm x 22 mm x 73 mm
Weight : Approx. 35 g
For Connectors
USB (GR-DVX88/DVX77 only) : Type B
EDIT (GR-DVX88/DVX77 only) : ø3.5 mm, 2-pole
S-Video
Output :Y:1 V
(
p-p
)
, 75 Ω, analogue
C : 0.29 V
(
p-p
)
, 75 Ω, analogue
JLIP (GR-DVX44 only) : ø3.5 mm, 4-pole
PC (DIGITAL PHOTO)
(GR-DVX44 only) : ø2.5 mm, 3-pole
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
