EN99
For Connectors
Video output :1 V
(
p-p
)
, 75 Ω, analogue
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
DV Input/output : 4-pin, IEEE 1394 compliant
Headphone output : ø3.5 mm, stereo
AC Power Adapter/Charger
AA-V51EA, AA-V51A, AA-V51A-S, AA-V51SH or AA-V51ED
Power requirement : AC 110 V to 240 V`, 50 Hz/60 Hz
Power consumption : 23 W
Output
Charge : DC 7.2 V
, 0.77 A
VTR : DC 6.3 V
, 1.8 A
Dimensions (W x H x D) : 68 mm x 45 mm x 110 mm
Weight
AA-V51EA : Approx. 270 g
AA-V51A : Approx. 260 g
AA-V51A-S : Approx. 260 g
AA-V51SH : Approx. 330 g
AA-V51ED : Approx. 260 g
Docking Station CU-V502E or CU-V502ED
For General
Dimensions (W x H x D) : 55 mm x 36 mm x 107 mm
Weight : Approx. 89.9 g
For Connectors
S
Output :Y:1 V
(
p-p
)
, 75 Ω, analogue
C : 0.29 V
(
p-p
)
, 75 Ω, analogue
Input : Y : 0.8 V
(
p-p
)
– 1.2 V
(
p-p
)
, 75 Ω, analogue
C : 0.2 V
(
p-p
)
– 0.4 V
(
p-p
)
, 75 Ω, analogue
VIDEO
Video output :1 V
(
p-p
)
, 75 Ω, analogue
Video input : 0.8 V
(
p-p
)
– 1.2 V
(
p-p
)
, 75 Ω, analogue
AUDIO
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
Audio input : 300 mV (rms), 50 kΩ, analogue, stereo
JLIP (EDIT) : ø3.5 mm, 4-pole, mini-head jack (compatible with RC-5325 plug)
PC (DIGITAL STILL) : ø2.5 mm, 3-pole
External microphone input : 506 µV (rms), high impedance unbalanced with ø3.5 mm (stereo)
PRINTER : For an optional video printer equipped with a PRINT DATA
connector
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
