EN11
Loading/Unloading A Cassette
1
Open the LCD monitor fully (GR-SXM46/SXM26/
FXM16/FXM161 only).
2
Slide EJECT until the cassette holder opens. Do not
use force to open.
3
Insert or remove a cassette. When inserting, make
sure the label is facing outward.
4
Press the Close button to close the cassette holder
until it locks into place.
5
Close the LCD monitor (GR-SXM46/SXM26/FXM16/
FXM161 only).
NOTES:
●
Closing the LCD monitor while the cassette holder is still
open may cause damage to the LCD monitor
(GR-SXM46/SXM26/FXM16/FXM161 only).
●
The cassette holder can’t be opened unless a power
supply is attached.
●
Make sure that the tape is not slack when loading the
cassette. If there is any slack, turn the gear on the
cassette in the direction of the arrow to take up the
slack.
●
Make sure the Erase Protection tab is in the position that
allows recording. If not, slide the tab. Some cassettes
have removable tabs. If the tab has been removed, cover
the hole with adhesive tape.
●
The cassette holder cannot be opened while the
camcorder is in the record mode.
Cassette holder
Erase Protection tab Gear
Turn to take
up slack.
EJECT SwitchClose Button
Close Button
EJECT Switch
Cassette holder
