EN51
Controls
1 Diopter Adjustment Control ................. Z pg. 15
2 Lens Cover Open/Close Ring................ Z pg. 16
3 Video Light Switch
[LIGHT OFF/AUTO/ON] (GR-SXM46/
SXM26/SX41/FXM161 only) ................. Z pg. 20
4 Snapshot Button [SNAPSHOT]
(GR-SXM46/SX41 only) ........................ Z pg. 21
5-Second Recording Button [5 SEC REC]
(GR-SXM26/SX21/FXM16/FXM161/
FX11 only) ........................................... Z pg. 19
5 •Power Zoom Lever [T/W] .................. Z pg. 18
•Speaker Volume Control [VOL.]
(GR-SXM46/SXM26/FXM16/
FXM161 only) ................................... Z pg. 33
6 •Picture Stabilizer Button
[P.STABILIZER] .................................. Z pg. 18
•Time Base Corrector Button ............... Z pg. 34
7 Program AE Button [P.AE] ..................... Z pg. 23
8 Fade/Wipe Button [EFFECT] ................. Z pg. 22
9 •Retake Rewind Button [RETAKE R] ..... Z pg. 19
•Quick Review Button [ R] ............. Z pg. 19
•Rewind Button [REW] ....................... Z pg. 33
0 •Retake Forward Button [RETAKE F] .... Z pg. 19
•Fast-Forward Button [FF] ................... Z pg. 33
! Stop Button [STOP] .............................. Z pg. 33
@ Play/Pause Button
[PLAY/PAUSE] ..................................... Z pg. 33
# •Select Wheel [PUSH] ........................ Z pg. 24
•Bright Dial [BRIGHT] (GR-SXM46/
SXM26/FXM16/FXM161 only) ....... Z pg. 16, 33
$ MENU/DISPLAY Button ................. Z pg. 17, 24
% Counter Reset/Memory Button
[COUNTER R/M] ................................. Z pg. 34
^ EJECT Switch ....................................... Z pg. 11
& Recording Start/Stop Button.................. Z pg. 16
* Power Switch
[ , OFF, AUTO, PRO.] .............. Z pg. 16, 33
( Battery Release Switch
[BATTERY RELEASE] .............................. Z pg. 7
) Close Button ........................................ Z pg. 11
Connectors
q DC IN Connector................................... Z pg. 7
The connectors w to t are located beneath the
cover.
w Video Output Connector ...................... Z pg. 36
e Audio Output Connector ..................... Z pg. 36
r S-Video Output Connector
(GR-SXM46/SXM26/SX41/SX21 only) ... Z pg. 36
t J Terminal [JLIP (Joint Level Interface Protocol)
Connector]
•Connect the editing cable when performing
Random Assemble Editing (Z pg. 44 – 47).
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
y Power Lamp ........................................ Z pg. 16
Other Parts
u Battery Pack Mount ............................... Z pg. 7
i Viewfinder ........................................... Z pg. 15
o Grip Strap ............................................ Z pg. 15
p •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor .................................. Z pg. 39
Q Video Light (GR-SXM46/SXM26/
SX41/FXM161 only) ............................. Z pg. 20
W Microphone......................................... Z pg. 43
E Eyepiece
R Speaker (GR-SXM46/SXM26/FXM16/
FXM161 only) ...................................... Z pg. 33
T LCD Monitor (GR-SXM46/SXM26/
FXM16/FXM161 only) .......................... Z pg. 17
Y Shoulder Strap Eyelets .......................... Z pg. 15
U Clock Battery Slot .................................. Z pg. 8
I Tripod Mounting Socket ....................... Z pg. 15
