Attaching the Core Filter
Attach the core filters to the cables. The core filter reduces
interference.
1 Release the stoppers on both ends of the core filter.
2 Run the cable through the core filter, leaving approx.
3 cm of cable between the cable plug and the core filter.
S-Video/Audio/Video cable
Wind the cable once around the outside of the core filter
as shown in the illustration.
USB cable, audio extension cable and AC adapter’s
cord
Wind the cable twice around the outside of the core filter
as shown in the illustration.
● Wind the cable so that it is not slack.
3 Close the core filter until it clicks shut.
NOTES:
● Take care not to damage the cable.
● When connecting a cable, attach the end with the core filter
to the camera.
How to Use the Audio Extension Cable
When using optional headphones, connect to the
provided audio extension cable (with a core filter
attached), then connect the audio extension cable to the
camera. The core filter reduces interference.
Stopper
Wind once.
Core filter (large)
3 cm
Wind twice.
Core filter (medium: USB cable,
small: audio extension cable and
AC adapter’s cord)
3 cm
S-Video/Audio/Video
cable
USB cable, audio extension
cable and AC adapter’s cord
Audio Extension Cable (provided)
Core Filter
Open the cover.
Headphones
To
