GETTING STARTED
EN 7
GETTING STARTED
MasterPage: Start_Right
Controls
A Lock Button (墌 pg. 19)
B Mode Button [MODE] (墌 pg. 19)
C Power Switch [OFF, , ] (墌 pg. 19)
D Battery/CF Card Cover Open Switch [OPEN]
(墌 pg. 14, 16)
E Delete Button [ ] (墌 pg. 21, 23, 24)
F Zoom Lever [T/W] (墌 pg. 20)
Speaker Volume Control (墌 pg. 21)
G Recording Start/Stop Button (墌 pg. 20)
H Reverse Search Button [w ( 3 )] (墌 pg. 21)
Left Button [w] (墌 pg. 26)
Flash Button [ ] (Used to change the flash mode.
Refer to the advanced operation manual. 墌 pg. 32)
I Play/Pause Button [49] (墌 pg. 21)
J Reverse Skip Button [r ( 2 )] (墌 pg. 21)
Up Button [r] (墌 pg. 26)
Backlight Compensation Button [ ]/Spot Exposure
Control Button (Used to engage backlight
compensation or spot exposure control. Refer to the
advanced operation manual. 墌 pg. 32)
K Forward Search Button [e ( 5 )] (墌 pg. 21)
Right Button [e] (墌 pg. 26)
Auto/Manual Mode Switch [ ] (墌 pg. 19)
L Forward Skip Button [t ( 6 )] (墌 pg. 21)
Down Button [t] (墌 pg. 26)
Manual Set Button [ SET] (墌 pg. 31)
M Information Button [INFO] (Used to display the file
information. Refer to the advanced operation manual.
墌 pg. 32)
N Menu Button [MENU] (墌 pg. 26)
Connectors
The connectors are located beneath the covers.
O USB (Universal Serial Bus) Connector (Refer to the
software installation and USB connection guide.)
P Headphone connector [ ] (墌 pg. 13)
Q S-Video/Audio/Video Output Connector [AV] (墌 pg. 25)
R DC Input Connector [DC] (墌 pg. 14)
Indicators
S Mode Lamp [ (video), (still image), (voice)]
(墌 pg. 19)
T Power/Charge Lamp (墌 pg. 14, 19)
U Access Lamp (Lights up or blinks when you access to
any files. Do not turn off the power or remove the
battery pack/AC adapter while accessing to files during
recording or playback.)
V Tally Lamp (Lights up while recording is in progress.
墌 pg. 20)
Other Parts
W Stereo Microphone
X Speaker (墌 pg. 21)
Y LCD Monitor
Z Battery/CF Card Cover (墌 pg. 14, 16)
a Flash Sensor
b Camera Sensor
c Flash
d Lens
e SD Card Cover [MEMORY CARD] (墌 pg. 16)
f Tripod Mounting Socket
g Hand Strap Eyelet (墌 pg. 12)
h Lens Cap Eyelet (墌 pg. 12)
GZ-MC200PAL.book Page 7 Tuesday, November 30, 2004 2:31 PM

JVC GZ-MC200 Specifications

General

Digital zoom	200 x
Optical zoom	10 x
Sensor type	CCD
Total megapixels	2.12 MP
Optical sensor size	1/3.6 \
Interface	USB 2.0
Resolution	1600 x 1200 pixels
Media types supported	Microdrive/CompactFlash Type II card, SD
Display diagonal	1.8 \
Built-in microphone	Yes

Weight and Dimensions

Weight	355 g
